EARTHSTONE OVENS PRE-ASSEMBLED INSTALLATION INSTRUCTIONS---U.L. LISTED

FOR COMMERCIAL USE ONLY

Figure 2

U.M.C. & N.F.P.A.

Figure 1

COMBUSTIBLES

3"MIN.

1" MIN.

105"

80"

HOOD

3"MIN.

COMBUSTIBLES

3"MIN.

FEED

OPENING

COMBUSTIBLES

1"
MIN.

1"MIN.

48"

MIN.

48"

MIN.

Figure 4

OUTSIDE DIAMETER
MODEL 60 - 33” X 32”
MODEL 90 - 50", MODEL 110 - 58"
MODEL 130 - 70”, MODEL 160 - 86"

ALL CLEARANCES SPECIFIED ARE
THE MINIMUM REQUIRED AIR SPACES

WARNING: DO NOT PACK REQUIRED AIR SPACES
WITH INSULATION OR OTHER MATERIALS.

Any adjacent combustible floor which projects
in front of the oven opening must be a minimum
of 30 inches away from each side of the door
opening and 36 inches from the front of the
door opening.

HOOD

FOR COMMERCIAL USE ONLY

Figure 3

U.M.C. & N.F.P.A.
