15 Ethernet interface
Page 19
14.5.13. Direct display
14.5.14. Replay (memory output)
HEADER PARAMETERS EXAMPLES
SCREEN P1 SCREEN FT
Defines the visualisation mode
P1 is FT, TEXT or XY
SCREEN:FT P1,P2,P3
Defines the F(T) mode
P1:VER or HOR : vertical or horizontal
P2:BOUNON ou BOUNOFF : display boundaries or not
Vertical display, full screen
P3:FULLON ou FULLOFF : full screen display or not
SCREEN:XY P1,P2 SCREEN:XY A3,A2
Defines the XY mode
P1=channel X is A1,A2, etc...
P2= channel Y is ALL for all valid channels, or A1,A2,...for a single
channel
SCOPE:TIMEBASE P1,P2
Defines the time base of scope mode
P1 = value ( from 1 to 500)
P2 = MILlisec, Sec, MIn or Hours : unit
SCOPE:RUN P1
Start or Stop the scope display
P1=ON or OFF
Start/Stop the scope display
SCOPE:RUN ? Returns scope display mode
SCOPE:TIMEBASE 500,MS;:SCREEN
FT;:PAGE SCOPE;:SCOPE:RESTART
change time Time and then display
scope screen in f(t) mode
PAGE SCOPE;SCREEN FT;:SCREEN
VER,BOUNON,FULLON
HEADER PARAMETERS EXAMPLES
OUTBloc P1,P2,P3 OUTBLOC 1,25.2,80
Defines the memory output block and output window. block 1 , beginning at 25.2 % and ending at 80 %
P1 = 1 to 128 block number
P2 = 0 to 100 (% in real number from the beginning)
P3 = 0 to 100 (% in real number to the end)
OUTBloc ? Returns the command
OUT:REC P1,P2 OUT:REC XY,200
Defines kind of plot on paper
P1: FT or XY kind of plot
OUT:REC FT,100
diagram F(t), 100 samples per mm.
OUT:REC ? Returns the command
PLOTRec P1
Start ou stop the plotting of the screen
P1=ON ou OFF
PLOTRec ? Returns the status of the plotting and the ratio of data written
READBLOC ? Reads in binary the output bloc defined by OUTBLOC OUTBLOC 2,0,100,READBLOC ?
Reading of block 2
- first 4 bytes give the total length of datas (N)
- N bytes of datas
diagram XY, size 200x200 mm on paper
P2 : Defines the reduction ratio in FT mode ( from 1 to 10000 step
1,2,5 ) or the width of the grid in XY mode (100, 200 or 250)
