17
Continued from previous column
Onboard Graphics
∙ 1x DVI-D port, support a maximum resolution of
1920x1200 @60Hz*
∙ 1x HDMI™ 2.0 b port, supports a maximum resolution of
4096x2160 @30Hz, 2560x1600 @60Hz* / **
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports ∙ 6x SATA 6Gb/s ports (From B550 chipset)
M.2 SSD Slots
∙ 1x M.2 slot (Key M)
• M2_1 slot (From CPU)
• Supports PCIe 3.0 x4
• Supports SATA 6Gb/s
• Supports 2260/ 2280/ 22110 storage devices
RAID
∙ Supports RAID 0, RAID 1 and RAID 10 for SATA storage
devices
Audio
Realtek® ALC897 Codec
∙ 7.1-Channel High Definition Audio
LAN ∙ 1x Realtek® RTL8111H LAN controller
Power Connectors
∙ 1x 24-pin ATX main power connector
∙ 1x 8-pin ATX 12V power connector
Internal USB
Connectors
∙ 1x USB 3.2 Gen 1 5Gbps connector (From B550 chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
∙ 2x USB 2.0 connectors (From B550 chipset)
• Supports additional 4 USB 2.0 ports
Fan Connectors
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 4x 4-pin system fan connectors
System Connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x TPM module connector
∙ 1x Serial port connector
∙ 1x Parallel port connector
Continued on next column
