Event Panel System
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free (866) 245-6726
DMX TRAITS
2 Channel Mode
Channel Value
Function
1
0 - 255
Macros/programs
2
0 - 255
Speed/sound sensitivity control
(slow-fast)
3 Channel Mode
Channel Value
Function
1
0 - 255
Red ( 0% - 00% )
2
0 - 255
Green ( 0% - 100% )
3
0 - 255
Blue ( 0% - 100% )
4 Channel Mode
Channel Value
Function
1
0 - 255
Red ( 0% - 00% )
2
0 - 255
Green ( 0% - 100% )
3
0 - 255
Blue ( 0% - 100% )
4
0 - 255
DImming (0 - 100%)
7 Channel Mode
Channel Value
Function
1
0 - 255
Red ( 0% - 00% )
2
0 - 255
Green ( 0% - 100% )
3
0 - 255
Blue ( 0% - 100% )
4
0 - 255
Macros/programs
5
0 - 255
Speed/sound sensitivity control
(slow-fast)
6
1 - 255
Program fade (slow-fast)
7
1 - 255
DImming (0 - 100%)
14 Channel Mode
Channel Value
Function
1
0 - 255
Red 1 ( 0% - 00% )
2
0 - 255
Green 1 ( 0% - 100% )
3
0 - 255
Blue 1 ( 0% - 100% )
4
0 - 255
Red 2 ( 0% - 00% )
5
0 - 255
Green 2 ( 0% - 100% )
6
0 - 255
Blue 2 ( 0% - 100% )
7
0 - 255
Red 3 ( 0% - 00% )
8
0 - 255
Green 3 ( 0% - 100% )
9
0 - 255
Blue 3 ( 0% - 100% )
10
0 - 255
Red 4 ( 0% - 00% )
11
0 - 255
Green 4 ( 0% - 100% )
12
0 - 255
Blue 4 ( 0% - 100% )
13
1 - 255
Strobe (slow-fast)
14
1 - 255
DImming (0 - 100%)
26 Channel Mode
Channel Value
Function
1
0 - 255
Red 1 ( 0% - 00% )
2
0 - 255
Green 1 ( 0% - 100% )
3
0 - 255
Blue 1 ( 0% - 100% )
4
0 - 255
Red 2 ( 0% - 00% )
5
0 - 255
Green 2 ( 0% - 100% )
6
0 - 255
Blue 2 ( 0% - 100% )
7
0 - 255
Red 3 ( 0% - 00% )
8
0 - 255
Green 3 ( 0% - 100% )
9
0 - 255
Blue 3 ( 0% - 100% )
10
0 - 255
Red 4 ( 0% - 00% )
11
0 - 255
Green 4 ( 0% - 100% )
12
0 - 255
Blue 4 ( 0% - 100% )
13
0 - 255
Red 5 ( 0% - 00% )
14
0 - 255
Green 5 ( 0% - 100% )
15
0 - 255
Blue 5 ( 0% - 100% )
16
0 - 255
Red 6 ( 0% - 00% )
17
0 - 255
Green 6 ( 0% - 100% )
18
0 - 255
Blue 6 ( 0% - 100% )
19
0 - 255
Red 7 ( 0% - 00% )
20
0 - 255
Green 7 ( 0% - 100% )
21
0 - 255
Blue 7 ( 0% - 100% )
22
0 - 255
Red 8 ( 0% - 00% )
23
0 - 255
Green 8 ( 0% - 100% )
24
0 - 255
Blue 8 ( 0% - 100% )
25
1 - 255
Strobe (slow-fast)
26
1 - 255
DImming (0 - 100%)
Product Order Code
Description
EVENT PANEL SYS
Ultra-bright color panel with 288 10mm LEDs
Accessories Order Code
Description
ELAR WR
Wireless infrared remote (included)
