Specifications are subject to change without notice.
specifications
Video
Gain ...................................................... Unity
Signal type.............................................. proprietary analog signals
Connectors
All models .......................................... 1 female RJ-45
Video input and loop through — transmitter
Number/signal type
MTP T 15HD A AAP, MTP T 15HD A D,
MTP T 15HD A WM ............................. 1 analog RGBHV, RGBS, RGsB, RsGsBs,
component video, S-video, or composite
video
All other models ................................. 1 analog RGBHV, RGBS, RGsB, RsGsBs,
component video (with bi-level or tri-level
sync), S-video, or composite video
1 buffered RGBHV, RGBS, RGsB, RsGsBs
local monitor loop through (includes ID
bits)
Connectors
MTP T 15HD A AAP, MTP T 15HD A D,
MTP T 15HD A WM ............................. 1 female 15-pin HD
All other models ................................. 2 female 15-pin HD
Nominal level ......................................... 1 Vp-p for Y of component video and
S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of
component video
0.3 Vp-p for C of S-video
Minimum/maximum levels ..................... 0.3 V to 1.45 Vp-p
Impedance ............................................ 75 ohms
Horizontal frequency .............................. 15 kHz to 130 kHz
Vertical frequency ................................... 30 Hz to 150 Hz
DC offset (max. allowable) ...................... 250 mV
Video output — receiVers
Number/signal type
D and WM models ............................. 1 analog RGBHV, RGBS, RGsB,
RsGsBs, component video, S-video, or
composite video
All other models .................................. 1 set of proprietary analog signals
1 analog RGBHV, RGBS, RGsB, RsGsBs,
component video, S-video, or composite
video
Connectors
D and WM models ............................. 1 female 15-pin HD
All other models ................................. 1 female RJ-45
1 female 15-pin HD
Nominal level ......................................... 1 Vp-p for Y of component video and
S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of
component video
0.3 Vp-p for C of S-video
Minimum/maximum levels ..................... 0.3 V to 1.45 Vp-p
Impedance ............................................. 75 ohms
DC offset
MTP C7 RL 15HD Series, MTP 15HD A
Series .................................................. <±35 mV with input at 0 offset
All other receivers ................................ <±20 mV with input at 0 offset
sync
Input type (transmitters) ........................ RGBHV, RGBS, RGsB, RsGsBs
Output type (receivers) ........................... RGBHV, RGBS, RGsB, RsGsBs
Standards ............................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level (transmitters) ........................ 3.5 V to 5.5 Vp-p, unterminated
Output level (receivers) ........................... TTL: 4.0 V to 5.0 V p-p, unterminated for
RGBHV, RGBS
audio
Number/signal type ................................ 1 set of proprietary analog signals from an
MTP transmitter
Connector .............................................. 1 female RJ-45
Gain ...................................................... Unbalanced output: 0 dB; balanced output:
+6 dB
Frequency response ................................ 20 Hz to 20 kHz, ±1 dB
THD + Noise ........................................... 0.15% @ 1 kHz, 0.3% @ 20 kHz at
nominal level
S/N ...................................................... >70 dB at maximum output (unweighted)
Stereo channel separation
MTP T 15HD A AAP, MTP T 15HD A D,
MTP T 15HD A WM .............................. >60 dB @ 1 kHz
CMRR ..................................................... >43 dB @ 20 Hz to 20 kHz
audio input — mtp t 15hd a series transmit
Number/signal type ............................... 1 stereo, unbalanced
Connectors ............................................. (1) 3.5 mm mini stereo jack
Impedance ............................................. >10k ohms, unbalanced
Nominal level ......................................... +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level
MTP C7 T 15HD A .............................. +12 dBu, (unbalanced) at 1%THD+N
All other models ................................. +18 dBu, (unbalanced) at 1%THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
audio output
Number/signal type
MTP 1500RL 15HD A,
MTP 1500RL 15HD A SEQ,
MTP R 15HD A Series,
MTP C7 RL 15HD A,
MTP C7 RL 15HD A SEQ ....................... 2 mono, balanced/unbalanced
MTP R 15HD RSA D ............................. 1 mono, balanced/unbalanced
MTP T 15HD A AAP,
MTP T 15HD A D,
MTP T 15HD A WM local stereo output .. 1 stereo, balanced/unbalanced
Connector
MTP 1500RL 15HD A,
MTP 1500RL 15HD A SEQ,
MTP T/R 15HD A Series,
MTP C7 RL 15HD A,
MTP C7 RL 15HD A SEQ ....................... (1) 3.5 mm captive screw connector, 5 pole
MTP R 15HD RSA D ............................. (1) 3.5 mm captive screw connector, 5 pole
(uses 3 poles)
Impedance ............................................. 50 ohms balanced, 100 ohms balanced
Gain error ............................................... ±1 dB channel to channel
Nominal level ......................................... +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level
MTP T 15HD A Series (Hi-Z) ................ >+23 dBu, balanced or unbalanced at 1%
THD+N
MTP T 15HD A Series (600 ohms) ....... >+17 dBm, balanced or unbalanced at 1%
THD+N
All other models ................................. >+18 dBm, unbalanced at 1% THD+N
control/remote — external device (pass-through, unidirectional or bidirectional), mtp r 15hd rsa d only
Serial control port input/output .............. 1 set of proprietary signals on a female
RJ-45 jack
Serial control port output/input .............. RS-232 via 3 poles of a 3.5 mm captive
screw connector, 5 pole
Baud rate and protocol ........................... 9600 baud, 8 data bits, 1 stop bit, no parity
general
External power supply ............................ 100 VAC to 240 VAC, 50/60 Hz, external;
to 12 VDC, 2 A, regulated
Temperature/humidity ............................ Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Product weight
MTP 4T 15HD RS ................................ 6.0 lbs (2.7 kg)
MTP 1500RL 15HD Series .................... 2.5 lbs (1.1 kg)
MTP R 15HD RSA D,
MTP T/R 15HD RS,
MTP R 15HD RS SEQ,
MTP T/R C7 15HD Series,
MTP 15HD A Series ............................. 0.4 lbs (0.2 kg)
Shipping weight
MTP 4T 15HD RS ................................ 10 lbs (5 kg)
MTP 1500RL 15HD Series .................... 5 lbs (3 kg)
MTP R 15HD RSA D,
MTP T/R 15HD RS,
MTP R 15HD RS SEQ,
MTP T/R C7 15HD Series,
MTP 15HD A Series ............................. 2 lbs (1 kg)
Vibration ................................................. ISTA 1A in carton (International Safe Transit
Association)
Regulatory compliances
Safety .................................................. CE, C-tick, CUL, UL
EMI/EMF ............................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF .................................................. 30,000 hours
Warranty ................................................. 3 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.
* For complete product specification see Extron.com
