Specifications
Model:
Envision EN9410e
Display Characteristics
Display Type 19“ active matrix Thin Film
Transistor Liquid Crystal Display
Viewable Diagonal Area 43.3 cm / 19”
Native (Maximum) Resolution 1,280 x 1,024 pixels
Colors 16.7 million (6bpp+dithering)
Dot Pitch 0.294 mm
User Interface
Controls Mains power switch, Automatic
image adjustment, 6 OSD buttons
On-Screen Display Functions Contrast, Brightness, Vert. & Hor.
Image Position, Phase, Pixel
Clock, Colour Management, OSD
Position, OSD Language, Status
Indicator
Input Signal
Line Frequency 31 - 83kHz multi-frequency
Image Frequency (Refresh Rate) 56 - 75Hz
Within the parameters detailed in
chapter 7
Video Signal RGB analogue (Positive polarity)
0.7 Vpp/75 Ohm
Synchronization TTL separate, composite TTL
