Envision Peripherals G912WA2 - Manual

G912wa2
Cabinet Color Black
Panel TFT Active Matrix LCD
VIS: 19" ( 48.3cm ) Widescreen, Diagonal
Hard Coating (3H), Anti-glare Treatment
Pixel Pitch 0.285mm x 0.285mm
Display Area 410.4mm x 256.5mm
Brightness 300 cd/m2 (typ)
Contrast Ratio 800:1 (typ)
Response Time 5ms (typ)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility VESA, WXGA+, SXGA, XGA, SVGA,VGA
Mac® Equipped With Analog VGA Dsub or DVI Port
Scanning Frequency Horizontal: 31K~81KHz
Vertical: 56~75 Hz
Pixel Frequency 135MHz
Maximum Resolution
Recommended Resolution
Resolutions Supported 1440x900x60Hz
1440x900@60Hz
720x400@70Hz, 640x480@60,67, 72, 75Hz
800x600@56, 60, 72, 75Hz, 832x624@75Hz
1024x768@60, 70, 75Hz, 1280x1024@60, 70, 75Hz,
1152x864@75Hz, 1280x720@60Hz, 1440x900@60Hz
Color 16.2M
Signal Input Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative
Digital Input DVI-D (TMDS) with HDCP*
Connectors Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power: (3-Pin Plug CEE22)
Audio: 3.5m Stereo
Power Source Universal 110~240VAC, 50/60Hz
Power Consumption 50Watts (Max)
Plug & Play DDC2B
EPA ENERGY STAR® Yes
User Control
Auto Adjust Key/ Exit, Decrease/ Audio,
MENU, Power
OSD Function Contrast, Brightness, H-Position, V-Position, Clock, Phase, Color
Management(9300k/ 6500k, 1 user mode, sRGB), OSD
Language, OSD Position, System Status/Frequency Info. Auto
Adjust, Volume, Mute
OSD Languages English, French, Spanish
Regulations cULus, FCC, CE, ISO 13406-2, Windows® Vista Premium Logo,
Built-in Speakers 1W x 2
Other Features
HD Compatible, VESA 100mm Wall Mount Compliant**,
Kensington Security Slot
Dimensions (WxHxD mm) Monitor: 446.2x364.3x213.6; Carton: 510x440x145
Dimensions (WxHxD inches) Monitor: 17.6x14.3x8.4; Carton: 20.1x17.3x5.7
Monitor Dimensions w/o Base (WxHxD) 446.2x292.1x66.3mm; 17.6x11.5x2.6 inches
Weight 10.8 lbs (4.9 kgs) Net
TBD
Loading Qty w/pallet 20' = 700 pcs.; 40' Std = 1540 pcs.
UPC Code 685417102587
E0807
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount arm & bracke
not included. Windows Vista and the Windows logo are trademarks or registere
