PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through
the distributor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your
equipment. Then determine the Part Number (not the Index Number) and the Description of each part from the following appropriate
illustration and list. Be sure to give all this information.
Furnace Model Number
Part Description
Furnace Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, IL 62222-0529
Index
No.
Part
Number
Description Index
No.
Part Number Description
1 13057 Outlet Tube - Inner Assembly (Includes 2 & 3) 23 R-942 Thermopile
2 M-177 Gasket - Outer Collar 24 DV-1004 Pilot Tubing
3 13104 Outlet Tube - Inner Welded Assembly 25 RH-238 Burner Door
4 13062 Inlet Tube - Inner Assembly (Includes 5 & 6) 26 DV-778 Gasket - Burner Door
5 M-178 Gasket - Inlet Collar 27 M-151-B Gasket - Pilot Burner
6 13106 Inlet Tube - inner Welded Assembly 28 DV-994 Pilot Shield
7 13064 Inlet Tube - Outer Assembly 29 R-2224 Pilot Burner with Orifice (Nat)
8 13059 Outlet Tube - Outer Assembly 29 R-2223 Pilot Burner with Orifice (LP)
9 13053 Vent Cap Welded Assembly 30 DV-772 Electrode and Wire Assembly
10 13051 Wall Mounting Bracket Assembly 31 DV-913 Casing Front (USA)
11 13089 Inlet Air Drop Chute Assembly 31 15700 Casing Front (Canada)
12 DV-762 & DV 763 Gasket - Air Drop Chute (2 Each Required) 32 P-86-43 Main Burner Orifice (DV-25T Nat)
13 DV-951 Casing Top 32 P-86-54 Main Burner Orifice (DV-25T LP)
14 DV-901 Heat Shield 32 P-86-38 Main Burner Orifice (DV-35T Nat)
15 13278 Inner Casing Assembly (USA) 32 P-86-50 Main Burner Orifice (DV-35T LP)
15 15701 Inner Casing Assembly (Canada) 33 P-190 Manifold
16 RH-705 Casing Side (2 Required) 34 R-191 Manifold Union Assembly
17 M-176 Gasket - Flue Outlet Support 35 R-5600 Gas Valve (Nat) 7000 MVRLC
18 13094 Combustion Chamber (DV-25T) 35 R-5601 Gas Valve (LP) 7000 MVRLC
18 13091 Combustion Chamber (DV-35T) 36 DV-1003 Valve Bracket
19 M-155 Gasket - Lighting Hole 37 DV-764 & DV-765 Gasket - Chamber Support (2 Each Required)
20 DV-781 Lighting Hole Cover Assembly with Clear Mica 38 DV-908 Valve Shield
21 DV-064 Cover Plate 39 R-854 Piezo Ignitor
22 DV-988 Burner (DV-25T) Not Shown R-1081 Pilot Orifice (Nat)
22 DV-990 Burner (DV-35T) Not Shown R-1089 Pilot Orifice (LP)
Not Shown R-5788 Wall Thermostat - Millivolt
Not Shown 13271 Wall Thermostat Bracket
Not Shown DV-885 Hardware Package
HOW TO ORDER REPAIR PARTS
PARTS LIST
