Ezcinema series dimensions table – Elite Screens exCinema User Manual
Page 8
7
ezCinema Series Dimensions Table
Unit: mm
Model
Case
Length (A)
Screen
Width
(A1)
View
Width
(A2)
Upper Scroll
Bar Length
(A3)
Overall
Height
(B)
Screen
Height
(B1)
View
Height
(B2)
B3
Case
Height
(D)
Case
Width
(C)
N.W.
(KGS)
F60NWV
1410.0
1295.0
1219.0
1379.0
1990.2
1854.2
914.4
878.0
95.0
118.0
6.2
F72NWV
1661.0
1539.0
1463.0
1631.0
1944.5
1808.5
1097.3
700.0
95.0
118.0
6.9
F84NWV
1891.0
1783.0
1707.0
1861.0
2102.0
1966.0
1280.2
675.0
95.0
118.0
7.7
F100NWV
2224.0
2108.0
2032.0
2194.0
2168.0
2032.0
1524.0
497.0
95.0
118.0
9.0
F120NWV
2629.0
2514.0
2438.0
2599.0
2557.0
2413.0
1828.8
1086.0
100.0
126.0
13.3
F135NWV
2925.0
2819.0
2743.0
2895.0
2785.6
2641.6
2057.4
1086.0
100.0
126.0
18.0
F150NWV
3235.0
3124.0
3048.0
3205.0
3014.2
2870.2
2286.0
960.0
100.0
126.0
19.3
F80NWH
1958.0
1847.0
1771.0
1928.0
2020.7
1884.7
995.7
878.0
95.0
118.0
7.7
F84NWH
2041.0
1936.0
1860.0
2011.0
2071.5
1935.5
1046.5
878.0
95.0
118.0
8.7
F100NWH
2401.0
2290.0
2214.0
2371.0
2091.8
1955.8
1244.6
700.0
95.0
118.0
9.1
F120NWH
2845.0
2733.0
2657.0
2815.0
2221.7
2077.7
1493.5
1086.0
100.0
126.0
15.5
F135NWH
3177.0
3065.0
2989.0
3147.0
2409.7
2265.7
1681.5
1086.0
100.0
126.0
18.5
F150NWH
3510.0
3397.0
3321.0
3480.0
2595.1
2451.1
1866.9
1086.0
100.0
126.0
20.2
Unit: Inch
Model
Case
Length (A)
Screen
Width
(A1)
View
Width
(A2)
Upper Scroll
Bar Length
(A3)
Overall
Height
(B)
Screen
Height
(B1)
View
Height
(B2)
B3
Case
Height
(D)
Case
Width
(C)
N.W.
(LBS)
F60NWV
55.5
51.0
48.0
54.3
78.4
73.0
36.0
34.6
3.7
4.6
13.6
F72NWV
65.4
60.6
57.6
64.2
76.6
71.2
43.2
27.6
3.7
4.6
15.1
F84NWV
74.4
70.2
67.2
73.3
82.8
77.4
50.4
26.6
3.7
4.6
17.0
F100NWV
87.6
83.0
80.0
86.4
85.4
80.0
60.0
19.6
3.7
4.6
19.8
F120NWV
103.5
99.0
96.0
102.3
100.7
95.0
72.0
42.8
3.9
5.0
29.3
F135NWV
115.2
111.0
108.0
114.0
109.7
104.0
81.0
42.8
3.9
5.0
39.6
F150NWV
127.4
123.0
120.0
126.2
118.7
113.0
90.0
37.8
3.9
5.0
42.4
F80NWH
77.1
72.7
69.7
75.9
79.6
74.2
39.2
34.6
3.7
4.6
16.9
F84NWH
80.4
76.2
73.2
79.2
81.6
76.2
41.2
34.6
3.7
4.6
19.1
F100NWH
94.5
90.2
87.2
93.3
82.4
77.0
49.0
27.6
3.7
4.6
20.0
F120NWH
112.0
107.6
104.6
110.8
87.5
81.8
58.8
42.8
3.9
5.0
34.1
F135NWH
125.1
120.7
117.7
123.9
94.9
89.2
66.2
42.8
3.9
5.0
40.7
F150NWH
138.2
133.7
130.7
137.0
102.2
96.5
73.5
42.8
3.9
5.0
44.4
*Measurement dimensions are intended as a reference only and subject to change without notice. Note: Data Error may be ±1"
B
3
