Installation
(continued)
Trim-Out
All system wire runs are pulled through the PF2 frame. Lay the PSP6
front panel (attached to the PF2) on the floor in front of the frame
and make all connections. Dress the wires in neat bundles and then
carefully place the PSP6/PF2 back into the frame and secure using
the four included screws.
Wire Runs
