Easy Installation in Just a Few Steps
Dimensions
SS-82W Cut Out Info
In a few rare occasions, the grille's diameter may slightly
vary due to the tension of the mounting screws. This may
make it rather difficult to mount the grille.
To solve this issue, simply cut four (4) “V” notches to rim of
the grille as illustrated in the side images. This will allow the
grille to flex and be easier to mount.
WARNING
Please do n
ot use power drill when tightening the
mounting screws of the speaker.
Simply tighten the screws by hand using a
screwdriver to prevent the mounting ears from
snapping.
Cut the hole:
using the provided cut-
out template
Wire the speaker:
using the non-obtrusive
spring-loaded speaker
terminals
Mount the speaker:
by utilizing the
Turn-N-Lock™
installation
mechanisms
