Electro-Voice Sx500+ - Manual (Page 7)

Sx500+ 400-Watt Two-Way Speaker System
Sx500+ 400-
W
att T
w
o
-W
ay Speaker System
7
Figure 7 — Sx500+ Dimensions Figure 8 — Sx500+ enclosure with Mb500 wall/
ceiling mounting bracket
Figure 9 — Sx500+ enclosure with Mb700
forged eyebolt attachment kit
Figure 6 — Sx500+Full-Range Impedance
Curve
838 mm
(33.0 in.)
448 mm
(17.6 in.)
202 mm
(8.0 in.)
673 mm
(26.5 in.)
101 mm
(4.0 in.)
202 mm
(8.0 in.)
METRIC (M8 X 1.25) METAL INSERTS
FOR SUSPENDING ENCLOSURES
WITH KITS (EIGHT PLACES)
101 mm
(4.0 in.)
