Tiling displays – LG VL5G-M 49" Full HD IPS LED Video Wall Display User Manual

Page 23

background image

23

ENGLISH

Tiling Displays

How to Mount the Set

Example of 2 x 2 Tiling

Using the screws for attaching the VESA wall mount, mount the set to the wall mount plate or the wall.

Screws for attaching the VESA wall

mount (M6)

(Unit: mm (inches))

600

(23.6)

400

(15.7)
