7
1.) OPEN Switch – Slide to the right to unlock and open the CD door.
2.) HOLD On/Off Switch.
3.) CD Door.
4.) MODE Button - To select the playback mode: Repeat 1/All or Intro.
5.) RANDOM Button.
6.) PROGRAM Button.
7.) SKIP/SEARCH Reverse Button.
8.) SKIP/SEARCH Forward Button.
9.) LCD Display – Shows Track number, Program, Repeat, Random, and Intro
modes.
10.) PLAY/PAUSE Button.
11.) STOP Button.
12.) Battery Compartment (Bottom Cabinet).
13.) DC IN 4.5V Input Jack – Connect an AC adapter (not included) to this jack to
use 120V 60Hz house current.
14.) LINE OUT Jack – Connect to an external audio equipment input .
15.) PHONES Jack – Connect stereo headphones, included, to this jack.
16.) VOLUME Control – Raises or lowers the volume.
17.) BASS On/Off Switch.
LOCATION OF CONTROLS AND INDICATORS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
