West Penn Plenum-Rated 254246 23 AWG 4-Pair Cat 6 Unshielded Cable (1000', Blue) - Manual

CONDUCTOR PARAMETERS -
Number Of Pairs 4
AWG Size 23
Conductor Stranding Solid
Conductor Type Bare Copper
Nominal DCR 22 O hm/1000ft
INSULATION PARAMETERS -
Insulation Type Flouropolymer
Insulation Color Code 1.Blue,WH-Blue 2.Orange,WH-Orange 3.Green,WH-Green 4.Brown, WH-Brown
SHIELDING PARAMETERS -
Shield Type Unshielded Twisted Pair (UTP)
ELECTRICAL CHARACTERISTICS -
Nominal Impedance 100 Ohm
Nominal Capacitance Between Conductors 15 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Total Number of Conductors 8
Jacket Type Flexible Plenum
Nominal Cable O.D. 0.225 in
Plenum Yes
NEC UL Rating CMP - CMP-LP
RoHS Compliant Yes
ANSI/TIA Category Category 6 TIA/EIA 568C.2
TIA Test ANSI/TIA-568-C.2
Other Standards CMP-LP - CL3P-LP (0.5A)
Pull Tension 40 lbs
Bend Radius 1.125 in
Cable Weight 27 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
Nominal Velocity of Propagation (VP) 72 %
Delay Skew 45 ns/100m
UL Flammability NFPA 262 Plenum
CSA Flammability FT6
Operating Range -0 to 75 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
254246
4 Pair 23AWG UTP Category 6 CMP
10/100/1000 BaseT Ethernet, IP CCTV, Digital Integration, HDBaseT
Toll Free: 800-245-4964 | [email protected] | www.westpennwire.com
