DMX TRAITS
16-Bit Basic Mode:
Channel Value
Function
1
0 - 255
PAN 8-bit
2
0 - 255
PAN fine 16-bit
3
0 - 255
TILT 8-bit
4
0 - 255
TILT fine 16-bit
5
0 - 255
Color Wheel
6
0 - 255
Cyan 0 to 100%
7
0 - 255
Magenta 0 to 100%
8
0 - 255
Yellow 0 to 100%
9
0 - 255
CTO 0 to 100%
10
0 - 255
Gobo Wheel 1
11
0 - 255
Gobo Wheel 1 Index &
Continuous Scroll
12
0 - 255
Gobo Wheel 2
13
0 - 255
Gobo wheel 2 index &
continuous scroll
14
0 - 255
Prism & prism gobo effect macros
15
0 - 255
Prism index & prism rotation
16
0 - 255
Focus
17
0 - 255
Motorized zoom
18
0 - 255
Shutter/strobe
19
0 - 255
Dimmer
20
0 - 255
Iris
21
0 - 255
Frost
22
0 - 255
Animation wheel
23
0 - 255
CMY speed
24
0 - 255
Pan/tilt speed
25
0 - 255
Color macros
26
0 - 255
Lamp on/off, reset,
internal programs
16-Bit Extended Mode:
Channel Value
Function
1
0 - 255
PAN 8-bit
2
0 - 255
PAN fine 16-bit
3
0 - 255
TILT 8-bit
4
0 - 255
TILT fine 16-bit
5
0 - 255
Color Wheel
6
0 - 255
Color Wheel Fine 16-bit
7
0 - 255
Cyan 0 to 100%
8
0 - 255
Cyan Fine 16-bit
9
0 - 255
Magenta 0 to 100%
10
0 - 255
Magenta Fine 16-bit
11
0 - 255
Yellow 0 to 100%
12
0 - 255
Yellow Fine 16-bit
13
0 - 255
CTO 0 to 100%
14
0 - 255
CTO Fine 16-bit
15
0 - 255
Gobo Wheel 1
16
0 - 255
Gobo Wheel 1 Index &
Continuous Scroll
17
0 - 255
Gobo Wheel 1 Fine Indexing
18
0 - 255
Gobo Wheel 2
19
0 - 255
Gobo Wheel 2 Index &
Continuous Scroll
20
0 - 255
Gobo Wheel 2 Fine Indexing
21
0 - 255
Prism & prism/gobo effect macros
22
0 - 255
Prism index & prism rotation
23
0 - 255
Prism fine 16-bit
24
0 - 255
Focus
25
0 - 255
Focus Fine 16-bit
26
0 - 255
Zoom
27
0 - 255
Zoom fine 16-bit
28
0 - 255
Shutter/strobe
29
0 - 255
Dimmer 0-100%
30
0 - 255
Dimmer fine 16-bit
31
0 - 255
Iris
32
0 - 255
Iris fine 16-bit
33
0 - 255
Frost
34
0 - 255
Animation wheel
35
0 - 255
CMY speed
36
0 - 255
Pan/tilt speed
37
0 - 255
Color macros
38
0 - 255
Lamp on/off, reset,
internal programs
