Elinchrom D-Lite RX One/One Softbox To Go Kit - Manual (Page 2)

Elinchrom SA - D-Lite RX ONE - 10.2015
No guarantee for misprints - Elinchrom LTD
Av. de Longemalle 11, P. O. Box -458, CH-1020 Renens, Switzerland,
Tel. : + 41 21 637 26 77 Fax: +41 21 637 26 81 E-mail: [email protected]
www.elinchrom.com
Quick Start Guide
Please check all security documents before use !
DOWNLOAD THE USER GUIDE
http://bc.gs/um
Obtain the complete user guide using
this link:
DOWNLOAD CONFORMITY
http://bc.gs/ec
Find your declaration for EC and USA & Canada
conformity here:
DECLARATION OF CONFORMITY USA AND CANADA
EN This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
This product complies with the Canadian ICES-003 Class B specifications.
FR Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes(1) ce dispositif ne doit pas produire de
brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement. Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
Radiation Exposure Statement
EN
This equipment complies with portable RF exposure limit in Canada and the USA set forth an uncontrolled
environment and is safe for intended operation as described in this manual. Further RF exposure reduction can
be achieved if the product can be kept as far as possible from the user body.
FR Le produit est conforme aux limites d'exposition pour les appareils portables RF pour les Etats- Unis et le
Canada établies pour un environnement non contrôlé. Le produit est sûr pour un fonctionnement tel que décrit
dans ce manuel. La réduction aux expositions RF peut être augmentée si l’appareil peut être utilisé aussi loin
que possible du corps de l’utilisateur.
FCC Class B Compliance note
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/television technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
This device is limited to operation on permissible Part 15 frequencies, and is does not have the ability to be
configured by end users or professional installers to operate outside the authorized bands.
Phone: +41 21 637 26 77
Fax: +41 21 637 26 81
Email: [email protected]
Product name: D-Lite RX ONE
Trade name: ELINCHROM
Model number(s): 20485.1
Name of responsible party: Elinchrom LTD
Av. de Longemalle 11
1020 Renens / Switzerland
TROUBLESHOOTING
-
E1
Overvoltage
detected
Switch unit OFF, wait 2 minutes and switch unit ON again. If the
error shows up again the unit requires a check up at the Elinchrom
service centre
E2 Overheating
Wait until the unit has cooled down. The unit will switch back to
normal operation as soon as temperature decreases to normal
working level.
E3
Auto dump
function fault
The Unit has detected a time out in the ADF mode. Switch the unit
OFF, wait 2 minutes and switch the unit ON again; use the Test
release button for power reduction. If the error shows up again the
unit requires a check up at the Elinchrom service centre.
E4 Charge fault
Unit has detected a time out during recharging. Switch unit OFF, wait
2 minutes and switch unit ON again. If the error shows up again the
unit requires a check up at the Elinchrom service centre.
E5
Mains supply
fault
Unit has detected a mains supply fault. Check your mains cord and
mains
installation sockets. Switch unit OFF, wait 2 minutes and switch unit
ON again. If the error shows up again the unit requires a check up at
the Elinchrom service centre.
E8
Fan management
fault
Unit has detected a FAN management problem due to overheating.
Wait until the unit has cooled down. Check if the FAN is blocked.
If the error shows up again the unit requires a check up at the
Elinchrom service centre.
