REPLACING THE FLASHTUBE
1. Remove the battery and USB-C cable if you were
using Active Charge.
2. Wait 45 min. whilst the internal discharging is in
progress. Flashtube and internal reflector dish can
be hot!
3. To remove the glass dome, you
require a Torx TX10 screw driver.
Remove the three screws which
holds the glass dome with the
metal ring on the inner reflector
dish.
4. Never touch flashtubes, please use gloves. Pull the
flashtube carefully out. HIGH VOLTAGE! Never touch
broken flashtubes or electrodes! In this case remove
the flashtube with an isolated clamp!
5. Insert a new flashtube, please use gloves.
6. Use only the original Elinchrom flashtube for this unit,
third party flashtubes may damage the flash unit.
7. Please check that the trigger contact fork firmly grips
the flashtube.
8. Re-mount the glass dome with the metal ring by using
the 3x TX10 screws.
9. Ensure that all parts are in place and test the unit.
