MSI MAG401QR 40" 1440 155 Hz Ultrawide Gaming Monitor - Manual (Page 7)

7
Getting Started
1
Power LED
Lit in white after the monitor is turned on. If no signal input, the LED will
turn into orange. Lit in orange when the monitor is in Stand-by mode.
2
Macro Key
To activate OSD Application.
3 Power Button & Navi Key
4 Power Jack
5 Kensington Lock
6 Headphone Jack
7 HDMI™ Connector
Supports 4K@60Hz as specified in HDMI™ 2.0.
8
DisplayPort
Supports 3440x1440@155Hz as specified in DisplayPort 1.4a.
9
USB Type-C Port
This port supports DisplayPort Alternate (DP Alt) Mode and up to 20V/3.25A
(65W) power delivery.
10
USB 2.0 Type-B Upstream Port
For USB Upstream Cable.
⚠
Important
Check the package for USB Upstream Cable
and connect it to the PC and monitor. Once
this cable is connected, the USB Type-A
Downstream Ports on the monitor will be
ready for use.
To PC
To Monitor
11 USB 2.0 Type-A Port
