TO AVOID KICKBACK
1. Hold the chain saw firmly with both
hands.
2. Don’t let the nose of the guide bar
contact any obstruction.
3. Tip contact may suddenly move the
guide bar upward and backward,
which may cause serious injury.
Part Number 900191-30131
Carburetor adjustment
- Idle speed
Carburetor adjustment
- High speed mixture
Carefully read the Instruction
manual
Wear eyes, ears and head
protection
Carburetor adjustment
- Low speed mixture
Oil and gasoline mixture
Symbol form/shape Symbol description/application Symbol form/shape Symbol description/application
Chain oiler adjustment Chain brake operation
Chain oil pump
Chain oil fill
DECALS
Locate these safety decals on your unit. The
complete unit illustration found in the “NOMEN-
CLATURE OF PARTS” section will help you locate
them.
Make sure the decal is legible and that you under-
stand and follow the instructions on it. If a decal
cannot be read, a new one can be ordered from
your ECHO dealer.
Emergency stop
Choke control “Cold Start”
position (choke closed)
STOP
SYMBOL FORM
Part Number X524-001810
REPLACEMENT BAR AND CHAIN
GUIDE BAR* CHAIN*
PART NO. TYPE LINKS
16” 16A0ED3757 OREGON 91VG 57
18” 18A0ED3762 OREGON 91VG 62
*Or equivalent
Note: There may be other replace-
ment components for achieving
kickback protection. For details,
please refer to the chain and bar
combination sheet shown in the
instruction manual.
Part Number X503-007391
WARNING!! Read and follow all
safety precaution in the instruction
manual. Failure to follow
instructions could result in serious
personal injury.
