22
CS-400
End of the guide bar may be placed at the
height of about 35 cm (14 in.).
35 cm
(14 in.)
AUTOMATIC CHAIN BRAKE
Kickback produced from the tip of the guide bar will
trip the automatic chain brake. To make sure that
the automatic chain brake operates properly, follow
these steps:
1. Stop the engine.
2. Hold the saw with the guide bar approximately
35 cm (14 in.) above a wooden surface. Right
hand should hold the rear handle, and left
hand should hold the front handle.
3. Release the front handle and drop the end of
the guide bar against the wooden surface.
4. The impact should lock the chain brake.
IMPORTANT
When checking the operation of the automatic
chain brake, use a soft surface substance like
wood to provide the impact so the chain is not
damaged.
Rear handle should be gripped lightly with the
right hand.
WINTER OPERATION
Use the winter plug to prevent carburetor trouble in
winter.
• Remove air cleaner cover. Remove plug from
warm weather position, and install into cold
weather “storage” position.
NOTE
For operation at normal temperature return the
plug to its original place. (5°C, 41°F)
It causes over heating of the engine.
Plug
Air cleaner cover
Warm weather position
Cold weather
“storage” position
