Eaton Electrical PVH131/141 User Manual
Page 3
g
NOTE
Right hand rotation shown. View
is opposite for left hand rotation.
Please refer to Overhaul Manual
M-2210-S.
U
NOTE
Use shims as required to obtain
0.01–0.10 mm (.0004–.004 in.) axial
shaft end play.
Ff
473764 Screw
(4 Req’d)
Torque 31-37 N.m.
(23-27 lb. ft.)
Ff
526758 Limiter
(2 Req’d)
Ff
Piston & Shoe S/A
(See table)
Ff
Shoe cage (See table)
Ff
526757 Spacer
(2 Req’d)
:
692941 Yoke S/A
J:
690339 Screw (2 Req’d)
Torque 3.6-4.4 N.m.
(2.3-3 lb. ft.)
J:
692948 Saddle bearing
J:
692949 Saddle bearing
J
388206 Bearing S/A
692944
876277
864310
Y
396102 O–Ring
513602 Plug
Torque 97-106 N.m.
(71-78 lb. ft.)
Y
396100 O–Ring
181792 Plug
Torque 75-83 N.m.
(40-43 lb. ft.)
Y
335659 O–Ring
470794 Screw
(3 Req’d)
Torque 7-9 N.m.
(5-6.6 lb. ft.)
692946 Cover
Y
864200 Shaft seal
(2 Req’d if dual seal)
194030 Retaining ring
(2 Req’d if dual seal)
Y
262355 O–Ring
[g
692152 Bias piston
g
526690 Spring
Y
262355 O–Ring
Ff
Rotating group kit (See table)
g
526754 Control rod
Torque 82-91 N.m. (60-67 lb. ft.)
Grade RC30 compound
Y
Available in double shaft
seal kit 02–102266
f
02-322898
J
Available in bearing kit 877426
NOTE
For satisfactory service life of these
components in industrial applications,
use full flow filtration to provide fluid
which meets cleanliness code 16/14/12
or cleaner.
[g
526752 Bias rod
Torque 82-91 N.m. (60-67 lb. ft.)
Grade RC30 compound
Shaft (See table)
g
526753 Control piston
:
Available in bearing/yoke
kit 02-334838
F
877419
Shaft
Type
Key
876177
3 – Splined thru-drive –
860594
12 – Splined thru-drive –
876176
16 – Straight keyed 633260
thru drive
860802 2 - Splined –
877042 3 - Splined
–
860593 12 - Splined –
876175 13 - Straight keyed 140282
Model
Designation
Piston & Shoe
S/A (9 req’d)
Cylinder
Block
Shoe
Cage
F
131 Size
f
141 Size
02-159749
02-306332
680628
928786
683791
928776
Note
Complete replacement via rotating
group kits is recommended.
[
Non-torque control models
Pump Type
131
527164 527163
131QI
864381
876045
131QP 913578 N/A
141
928774 934240
141QI
934242
934243
141QP
934241 N/A
RH
LH
Valve Plate Table
Rotating Group
Kit
f
Available in PVH141 rotating group kit.
F
Available in PVH131 rotating group kit.
Housing
Flange/Seal
-C-*S
-C-*D
-C3-*S
Housing (See table)
