EAGLE EVR-100 Operation Instructions 11
Display
LCD symbols and Meanings
Symbol Meaning
TX
Transmitting.
HI LO Transmission power. High (HI) 7W or Low (LO) 1W.
BUSY Receiver busy with an incoming signal.
WX Weather channel.
WX ALT Weather Alert. Alarm beeps will sound.
PRI Priority channel is selected.
SCAN Scanning channels.
DW Dual Watch mode.
ALL ALL channels scan mode.
C1 C2 C3 Shows which of the 3 favourite channels, if any, are selected, otherwise
blank.
(small)
(large) Channel selected.
UIC Selected Channel bank for VHF radio operations and regulations (USA,
International, Canada)
Low Battery warning (activates at 10.5V)
Channel is temporarily deleted from the ALL SCAN operation. D Indicates
a Duplex channel is selected, otherwise, blank for Simplex operation.
A B Channel suffix, if applicable.
D Duplex operation, otherwise, blank for simplex operation.
