20
Specifications
Internal Voltage
• +/- 60 V
Power supply
• Mains voltage: 230 V AC / 50 Hz; 115 V AC / 60 Hz
• Fuses: 230 V: T 6.3 A; 115 V: T 10 A
• Power consumption: max 1440 VA
• Standby power consumption: 0.3 W
Dimensions (incl. feet)
• (WxHxD) 10.94 x 8.07 x 14.76 in (278 x 205 x 375 mm)
Weight
• 55.3 lbs (25.1 kg), unit only
• 64.2 lbs (29.1 kg), shipping
AM P CTL/ 12V T RIG GER
Connect to
AMP CTL output of
SPL Preamplifier/DAC
for remote power on/off
OR
Use 12 V Trigger
AMP CTL/12V TRIGGER
Pin 1 = GND
Pin 2 = Hot (+)
Pin 3 = Cold (–)
TRIM TRIM
+ + –
R
R
2 ώ 2 ώ
L
L
–
INPUT SELECT
INP UT S ELE CT
RCA XLR
SPEAKER OUT PUT LEFT XLR WIRING
XLR WIRING SPEAKER OUTPUT LEFT
INPUT LEFT
INP UT L EFT
INPUT RIGHT
INPU T RIGH T
SPEAKER OUTPUT RIGHT
Minimum Load Minimum Load
SPEAKER OUT PUT RIGHT
• •
•
•
•
•
• •
•
•
•
•
0 -5.5
-5
-
4.5
-4
-3.5
-3 -2 .5
-
2
-1.
5
-1
-0
.5 • •
•
•
•
•
• •
•
•
•
•
0 -5.5
-5
-4.5
-4
-3.5
-3 -2. 5
-2
-1
.5
-1
-0
.5
I F R
