EPSON ActionNote

Internal Keyboard Connector (J14)

pin 3

pin 1

Internal Keyboard Connector Pin Assignments

Power Connector Pin Assignments

Internal Keyboard Connector (Jl5)

Internal Keyboard Connector Pin Assignments

Pin

Signal

1

caps Lock

2-12

Keyboard data line

DC-DC Power Connector (J12)

Power Connector Pin Assignments

Pin

Signal

Pin

Signal

1

Ground

12 Vcc

2

Ground

13 Vcc

3

Ground

14 Vcc

pin 22

pin 21

4

Ground

15 Vcc

5

EXTAC

1 6

+12 VDC

6

Ground

17

VCCSUS

7

BATLO

18

CHARGE

8

+24 VDC

19

Vin

9

LCD ON

20

CONTR VR+

AC-DC Power Connector (JP1)

pin 4

pin 2

LED Connector (J5)

LED Connector Pin Assignments

Pin

Signal

Pin

Signal

1

Ground

6

Charging

2

Hard disk drive LED

7

/LOSPD

3

caps Lock

8

BATTLO

4

Num Lock

9

Ground

Scroll Lock

10

I

Suspend/Resume Connector (J4)

Suspend/Resume

Connector Pin

Assignments

Pin

Signal

Pin

Signal

1

Ground

5

BL_VR+

2

CONTR_VR-

6

Ground

3

CONTR_VR+

7

Ground

A

RI VR

8

SUS/RES

1

0

11

21

FULLPON

22

CONTR VR-

7/27/93

ActionNote-
