Epson Stylus CX4100 - Manual

Specifications
www.epson.com.sg
www.epsonphoto.com.sg
Dealer’s Stamp
Sep 05
Printer Type Printing Method On-demand ink jet (piezoelectric)
Nozzle Configuration 90 nozzles each (Black, Cyan, Magenta,Yellow)
Print Quality Maximum Resolution 5760 x 1440 dpi (with Variable-Sized Droplet Technology)^
Minimum Ink Droplet Volume 3pl
Print Speed Black Text Memo (A4) Approx. 20.0 ppm (Draft)*1
Colour Text Memo (A4) Approx. 19.0 ppm (Draft)*2
Photo 4R (4” x 6”) Approx 49sec per photo (Draft)*3
Copy Speed Black Text Memo (A4) Approx. 18cpm (Draft)
Colour (DTP) A4 Approx. 17cpm (Draft)
Standalone Copier Number of Copies 1-9, 100
Usability Reduction/Enlargement Auto Fit Function
Copy Modes Standard, Small Margin, BorderFree™
Scan Technology Scanner Type A4, Flatbed colour image scanner
Optical Sensor Colour CIS line sensor
Optical Resolution 1200 x 2400 dpi 48 Bits In
Scanning Speed Monochrome A4 1200dpi 10msec/line
A4 600dpi 5msec/line
A4 300dpi 3.5msec/line
Colour A4 1200dpi 30msec/line
A4 600dpi 15msec/line
A4 300dpi 10msec/line
Paper Handling Paper Feed Method Friction Feed
Paper Hold Capacity Input paper tray: 100 sheets
Paper Sizes Cut sheet (A4, A5, A6, B5, Letter, Legal, Half Letter,
4R (4" x 6"), 5R (5" x 7") Envelope No. 10, DL, C6, 132x220mm
Print Margin 0mm top, left, right, bottom via custom settings in printer
driver otherwise 3mm, top, left, right and bottom
Max Paper Thickness Less than 0.52mm
Ink Cartridges High Capacity Black Ink (T0621) Approx. 400 pages*4
Standard Capacity Black Ink (T0631) Approx. 250 pages*4
Cyan Ink Cartridge (T0632)
Magenta Ink Cartridge (T0633)
Approx. 380 pages*5 (Composite Yield) #
Yellow Ink Cartridge (T0634)
Interface USB2.0( Hi-Speed)** for PC connections, USB Host for Pictbridge & USB Direct Print Connections
Input Data Buffer 64KB
Colour Matching ICM Profiles, sRGB (Win 98/ME/2000), Apple ColorSync2.0 Compatible
Noise Level 45dB(A) per ISO7779
Electrical Specification Rated Voltage AC 220~240V
Rated Frequency 50~60 Hz
Power Consumption Approx. 10W (per ISO10561 Letter Pattern)
Printer Software Printer Drivers Windows 98SE/ME/2000 and Windows XP
On CD-ROM Mac OS ® 9+, Mac OS ® X, 10.2 or later with USB
+Web support only
On-line Guide Yes
EPSON Specialty Media (with its suggested applications)
General Use Photo Quality Inklet Paper A4 C13S041786
Crafts Photo Quality Inklet Card A6 C13S041054
Photo Quality Inklet Card 5”x8” C13S041121
Photo Quality Self Adhesive Sheet A4 C13S041106
Photo Output Ultra Glossy Photo Paper A4 C13S041927E1
Ultra Glossy Photo Paper 4R (4” x 6”) C13S041926E1
Premium Glossy Photo Paper A4 C13S041794
Premium Glossy Photo Paper 4R (4” x 6”) C13S041863
Premium Glossy Photo Paper 5R (5” x 7”) C13S041464E1
Premium Semigloss Photo Paper A4 C13S041332
Premium Semigloss Photo Paper 4R (4” x 6”) C13S041925
Photo Paper A4 C13S041140
Photo Paper 4R (4” x 6”) C13S041255
Economy Photo Paper A4 C13S041579
Matte Paper-Heavyweight A4 C13S041259
Double Sided Matte Paper A4 C13S041570
For enquiries, contact your nearest EPSON sales representatives:
INDIA - (91) 80-305-15000, CALCUTTA - 287 1355/56,
CHENNAI - 820 3941/42, MUMBAI - 825 7286, NEW DELHI -
644 7201/2/3
INDONESIA - (62) 21-572-3161
MALAYSIA - (60) 3-562-88288
PHILIPPINES - (632) 813-6567
SINGAPORE - (65) 6337-7911, (65) 6586-3111
THAILAND / INDOCHINA - (662) 670-0680
EPSON is the registered trademark of
SEIKO EPSON CORPORATION.
All other product names and other
company names used herein are for
identification purpose only and may be
the trademarks or registered trademarks
of their respective owners.
EPSON disclaims any and all rights in
those marks.
Scan/Print samples shown herein are
simulations.
Specifications are subject to change
without notice.
Print Speed Data Printout
Patterns The thumbnail images
below show the printout patterns
used to determine print speed
specification.
SIMPLE LIFESTYLE IMAGING
MEETING YOUR INKDIVIDUAL ™ NEEDS
Weight = Approx. 6.8kg
181mm
430mm 354mm
*1
Black Text
*2
Colour Text
*3
Photo 4R
(4”x6”)
^ When printed on EPSON Premium Glossy Photo Paper
++ To use USB port, your PC must conform to PC98 specifications, and have Windows preinstalled. Consult the documentation provided with your
PC for further information about USB connectivity. Note also that printing errors may occur if non-standard cables or more than 2 USB hub connections
are used.
# Page Yield was measured by Epson original pattern.
*4
Black Text &
Graphics
*5
Colour Text
& Graphics
ALL-IN-ONE
Print Speed Note:
The print times shown in this
brochure are the average time for
multiple prints of the same page
over one time or time to print one
photo. Times are measured from
‘Print’ command to delivery of the
page in the tray. The speeds were
achieved using the following
system: 1Ghz Pentium III, 128MB
RAM, Windows XP, USB 1.1
interface. Print times will vary
depending on computer
configuration, settings application,
coverage and page complexity.
* 120 years on Epson Matte type media
• Under fluorescent (indoor display
condition) with glass mount.
• For use with EPSON Matte Paper -
Heavy Weight.
• The data is calculated by EPSON’s
accelerated test and it does not
mean EPSON guaranteed periods.
• The estimated longevity does not
indicate the colour changing and the
durability of the paper itself
• Lightfastness rating may vary
depending on papers
• This lightfastness test is a
simulation of colour fading in an
indoor preservation conditions that
you display your prints. Factors,
other than light, such as ozone,
temperature and humility can affect
the print life.
Lightfastness Test Criteria (Indoor
Display Condition)
Light source : Fluorescent light
Intensity : 70,000 lux
Temperature : 24°C
Humidity : 60%RH
Glass mount : 2mm, soda lime
Fade criteria : Pure YMC 30% loss at
OD=1
Display-life : Total illuminance /(500
lux x 10 hours
Calculation x 365 days=1 year)
*Test developed and conducted by EPSON.
Facts on Genuine Inks
Superior Image Quality
For prints as vivid as your memories. Epson inks are
designed to work specifically with your printer hardware,
and to deliver stable, long-lasting, photographic quality –
quality that cannot be matched by non-genuine inks.
Longer Print Life
For brilliant prints that last and last. Permanence, or how
long a print will last before noticeable fading when it’s on
display and exposed to light, is where non-genuine inks
really pale in comparison to Epson’s inks. In a recent
study, Henr y Wilhelm, a leading authority on photo
longevity, projected Epson inks to last up to 92 years
1
when used with Epson paper.
Greater Reliability
Because we value your time as much as you do. All ink
jet printers provide print-head nozzle cleaning cycles to
ensure reliable ink flow. Ink is used in these cleaning
cycles. According to a study conducted by Torrey Pines
Research, non-genuine inks require up to 25 times more
user-initiated cleaning cycles than Epson ink cartridges
2 .
Unbeatable Value
More prints per cartridge. Torrey Pines Research stated
that Epson inks “consistently outperformed non-genuine
ink brands” when it comes to the number of prints per
car tridge. In fact, the study showed that Epson inks
produces up to 114 more pages per black ink cartridge
and 19 more pages per colour car tridge
3 . Epson ink
prints up tp 30% more than non-genuine ink.
The Final Facts
The research proves not only that: “you get what you pay
for”, but with genuine Epson inks, you get substantially
more. For more on the advantages of using genuine
Epson inks versus non-genuine inks, go to
www.epson.com/genuineink.
EPSON STYLUS™
C82 INK TEST -
PRINT LIFE
INK BRANDS
G&G
0A100
RAINBOW LOGO
EPSON
DISPLAY PERMANENCE
(number of years)
(0.5)
(0.5)
(1)
(92)
1 PC World Magazine 9/03,
test conducted using EPSON
STYLUS™ C82 with EPSON
DURABrite™ Ink on EPSON
Matte Paper-Heavyweight
EPSON STYLUS™ COLOR 777 INK TEST
- NOZZLE CLEANING CYCLES PER 1000 PAGES
EPSON
BRAND E
BRAND F
1.8
45.7
44.9
2 Torrey Pines Research, test
of EPSON genuine ink vs.
non-genuine inks.
EPSON STYLUS™ C62 INK TEST - PAGE YIELD PER CARTRIDGE
BLACK INK COLOUR INK
494 237
380 218
3 Torrey Pines Research, test
of EPSON genuine ink vs.
non-genuine ink
EPSON
BRAND A
