Emerson Process Management BETTIS G01 - Manual (Page 49)

Bettis P/N 124840E
Revision “B”
Page 45 of 46
6.8 G8 TOOL STYLE AND WRENCH SIZE
ITEM
NO.
WRENCH
SIZE
ITEM
QTY
LOCATION OR
DESCRIPTION RECOMMENDED
TOOL STYLE
1-110 3/4” 12 Hex Cap Screws Socket
1-120 3/4” 4 Hex Cap Screws Socket
1-160 9/16” 8 Hex Cap Screws Socket
1-180 1-1/4” 2 Stop Screws Open End or Adjustable
3-20 3/4” Sq. 2 Tie Bar (female square) Open End or Adjustable
3-40 3/4” Sq. 1 Piston Rod Male Drive
3-90 2-3/4” 2 Standard Hex Nuts Socket
3-100 1-1/8” 8 Hex Cap Screws Socket
3-120 1-5/16” Sq. 1 Pipe Plug Open End or Adjustable
3-130 3/16” 2 Socket Cap Screws Allen
5-20 1-1/8” 8 Hex Cap Screws Socket
7-20 1-1/8” 8 Hex Cap Screws Socket
12 1” 1 Breather Assembly Socket
13 3/4” 2 Vent Check Assembly Open End
- 3/4” 1 Tension rod Male Drive
6.9 G10 TOOL STYLE AND WRENCH SIZE
ITEM
NO.
WRENCH
SIZE
ITEM
QTY
LOCATION OR
DESCRIPTION RECOMMENDED
TOOL STYLE
1-110 3/4” 16 Hex Cap Screws Socket
1-120 3/4” 4 Hex Cap Screws Socket
1-160 9/16” 8 Hex Cap Screws Socket
1-180 1-1/2” 2 Stop Screws Open End or Adjustable
3-20 3/4” Sq. 2 Tie Bar (female square) Open End or Adjustable
3-40 3/4” Sq. 1 Piston Rod Male Drive
3-90 3-1/2” 2 Standard Hex Nuts Socket
3-100 1-5/16” 8 Hex Cap Screws Socket
3-120 1-5/16” Sq. 1 Pipe Plug Open End or Adjustable
3-130 3/16” 2 Socket Cap Screws Allen
5-20 1-1/8” 8 Hex Cap Screws Socket
7-20 9/16” 4 Hex Cap Screws Socket
12 1” 1 Breather Assembly Socket
13 3/4” 2 Vent Check Assembly Open End
- 3/4” 1 Tension rod Male Drive
