Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distribu-
tor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equipment. Then
determine the Part Number (not the Index Number) and the Description of each part from the following appropriate illustration and list. Be sure to give
all this information . . .
Appliance Model Number
Part Description
Appliance Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Attention: When ordering parts, it is very important that part number and description of part coincide.
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
1
2
3
4
5
6
Index No. Part
Number Description
CHARRED OAK SUPER SIZE LOG SETS
LS-18C2S
1
R-9182 REAR LOG
2 R-8299 LEFT FRONT LOG
3 R-8300 RIGHT FRONT LOG
4 R-8302 Y BRANCH
5 R-8312 RIGHT TOP LOG
6 R-8313 LEFT TOP LOG
LS-24C2S
1
R-9183 REAR LOG
2 R-8304 LEFT FRONT LOG
3 R-8305 RIGHT FRONT LOG
4 R-8307 Y BRANCH
5 R-8315 RIGHT TOP LOG
6 R-8316 LEFT TOP LOG
LS-30C2S
1
R-9184 REAR LOG
2 R-8308 LEFT FRONT LOG
3 R-8309 RIGHT FRONT LOG
4 R-8311 Y BRANCH
5 R-8317 RIGHT TOP LOG
6 R-8318 LEFT TOP LOG
CHARRED OAK SUPER SIZE PARTS LIST & PARTS VIEW
HOW TO ORDER REPAIR PARTS
