Elkay Celebrity DCR252210 User Manual
Elkay, Celebrity
Cutout in
No. of
Countertop
1
1
/
2
" Dia.
(1
1
/
2
" Radius
Faucet
Minimum
Ship.
Model
Overall
Inside Bowl
Corners)
Holes
Cabinet
Wt.
Number
L
W
L
W
D
L
W
4" Center
Size
Lbs.
DCR252210
25
22
21
15
3
/
4
10
24
3
/
8
21
3
/
8
1, 2, 3, 4 or 5
30
14
1
/
2
GENERAL
Good quality Celebrity single bowl is seamlessly drawn of #20
gauge, type 304 (18-8) nickel bearing stainless steel. Self-
rimming. Exclusive trimmed corner design.
DESIGN FEATURES
Bowl Depth: 10".
Coved Corners: 3" vertical radius, 1-3/4" horizontal radius.
Bowl and Faucet Deck Recess: 3/16" total recess below out-
side edge of sink.
Finish: Exposed surfaces are machine polished to a highlighted
finish.
Underside: Fully undercoated to prevent condensation and
deaden sound.
OTHER
Drain Opening: 3-1/2".
Faucet Holes: 1, 2, 3, 4 or 5, 1-1/2" faucet holes as indicated,
4" center to center.
NOTE: Unless otherwise specified, sink is furnished with 3 faucet
holes.
OPTIONAL ACCESSORIES
Rinsing Baskets: LKRB2015 and LKERBSS.
Cutting Board: CB1516.
Elkay
2222 Camden Court
Oak Brook, IL 60523
Printed in U.S.A.
©2003 Elkay
(Rev. 11/03)
1-16D
www.elkayusa.com
Model DCR2522103
4"
21"
22"
15-3/4"
1-3/4" R
25"
10"
4"
3" R
Model DCR2522103 Illustrated
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
SINK DIMENSIONS (INCHES)*
*
Length is left to right. Width is front to back
.
Celebrity
®
Single Bowl Sink
20 Gauge – Type 304 – Self-Rim
Model DCR252210
®
S P E C I F I C AT I O N S
