Page 12
Western Reserve Controls
WRC-CANX-xx Series 4
PUB 14.1
User’s Manual
8
The WRC-CANX-XX has an 8-pole DIP switch.
•
Switch positions 1-4 are used to set the Network A baud rate.
•
Switch positions 5-8 are used to set the Network B baud rate.
The baud rates can be set independently, or one side can take its baud rate from the other side
(in the “Remote” setting).
The Autobaud detects from DeviceNet bauds.
For CANopen speeds, select the fix baudrate setting.
When both the CANX units are set to all open switch positions (remote-remote) it scans through
DeviceNet baudrates.
Table 4-1 Baud Rate Settings for Switches
Local
Position 1 Position 2
Position 3
Position 4
Baud rate
Remote
Position 5 Position 6
Position 7
Position 8
Meaning
125K
CLOSED
CLOSED
CLOSED
CLOSED
Fixed
250K
CLOSED
CLOSED
CLOSED
OPEN
Fixed
500K
CLOSED
CLOSED
OPEN
CLOSED
Fixed
Autobaud
CLOSED
CLOSED
OPEN
OPEN
Autobaud for DeviceNet
Bauds (125k,250k,500k)
9.6K
CLOSED
OPEN
CLOSED
CLOSED
Fixed
10K
CLOSED
OPEN
CLOSED
OPEN
Fixed
20K
CLOSED
OPEN
OPEN
CLOSED
Fixed
40K
CLOSED
OPEN
OPEN
OPEN
Fixed
50K
OPEN
CLOSED
CLOSED
CLOSED
Fixed
100K
OPEN
CLOSED
CLOSED
OPEN
Fixed
800K
OPEN
CLOSED
OPEN
CLOSED
Fixed
1M
OPEN
CLOSED
OPEN
OPEN
Fixed
Remote
OPEN
OPEN
OPEN
OPEN
Takes baud rate from the
opposite end device. If
both sides are remote,
Autobaud from either side.
Autobaud
ALL OTHER SWITCH POSITIONS
Autobaud
4.3. LED Operation
The WRC-CANX-XX Multiplexer has four (4) LED’s that provide visual status information to the
user about the product and the DeviceNet network. See Figure 4-1, Table 4-2, Table 4-3 and Table 4-4.
