Mpman ICR110 User Manual

Page 3

OPERATION(CONTINUED)

NORMAL RECORDING

This unit is capable of recording only when sound is heard. To use this feature, see the next page. For
normal recording, follow steps below.

NOTES:

. The built-in audio level automatically sets the recording level.

. To record another message, simply repeat step 3,the message number will increase by one.

. For normal voice levels, a distance of 5-9 inches is appropriate.

VOICE ACTIVATED (VOX)RECORDING

Voice activated recording will allow dictation only when you speak.

When the unit detects a pause of a few seconds, it will temporarily stop recording until it detects sound

again.

When the unit detects a pause of a few seconds, it will temporarily stop recording until it detects sound

again.

TO PLAY BACK MESSAGES

TO REPEATEDLY PLAY BACK MESSAGES

You can set the unit to repeat1 or all messages as follows:

TO CANCEL REPEAT PLAYBACK:

To cancel repeat playback, press the ERASE/REPEAT button once or twice until the REPEAT indicator

disappears from the display.

To cancel repeat playback, press the ERASE/REPEAT button once or twice until the REPEAT indicator

disappears from the display.

TO PAUSE A MESSAGE

Make sure the VOX switch on the
side of unit is set to OFF. Turn the

unit on, and select the desired sound

quality as described on page 6.

Select a File Folder by pressing the FILE/TIME

button (see page7).

Press the PLAY/STOP button

to see the

remaining recording time during recording. To pause

recording ,press the MODE/PAUSE

button

;PAUSE will blink in the display. To release

pause press the MODE/PAUSE button

again.

While in the standby mode, press the

REC/STOP button and the REC indicator will light

and the elapsed time will appear.

Speak into the built-in microphone or insert a

microphone into the MIC jack and speak to it with a

normal tone of voice. Press the REC /STOP button

again to stop recording.

OPERATION(CONTINUED)

Slide the VOX switch on the side of the

unit to the ON position. Turn the unit

on,and select the descried sound quality

as described on page 6.

Select a FILE Folder by pressing the

FILE/TIME button(see page7).

Press the REC/STOP button and the REC
indicator will light and the elapsed time will appear.
Speak into the built-in microphone or insert a
micro-phone into the MIC jack and when the unit
picks up sound, it will record. When not
recording ,the REC indicator will blink and
PAUSE will blink in the display until sound is
detected.
Press the REC/STOP button again to stop
recording.

NOTES:

.The first few sounds activate the recorder

and may not be recorded.

. A variation in voice level

during recording will not

stop the unit. two seconds of silence is

required to stop the recording.

. For constant recording, see previous page.

.To pause, press the MODE/PAUSE

.The built-in audio level automatically sets the

recording level.

. For normal voice levels, a distance of 5-9

inches is appropriate.

Turn the unit on and select a File

Folder by pressing the FILE/TIME

button(see page7).

Select the desired message number by pressing

the REV

or FWD

button; the message number and the message

length will appear in the display.

While in the standby mode, press the
PLAY/STOP button

; the unit will play

the currently selected message, then
stop. During playback,
the play indicator and the elapsed time of
the message will appear in the display.
You can check the message recording
time and date by pressing the
REC/STOP button

NOTES:
.To pause, press the MODE/ PAUSE

button; PAUSE will blink in the display. To
release pause, press the MODE/PAUSE
button again.

. For Clue and Review during playback,

simply press and hold the desired REV or
FWD button.
A chattering sound will be heard.

Release the button when the desired point
is reached.

.To skip or go back messages, simply press

and release the desired REV or FWD button
until the desired message number is
reached.

EARHONE JACK

For private listening, connect an earphone (not included) to this jack.

The speaker is automatically disconnected when the earphone plug is inserted in the jack.

OPERATION(CONTINUED)

REPEAT MESSAGE: While playing back a

message, press the ERASE/REPEAT

button

once, “REPEAT” will appear in the

display and the message playing

will repeat over and over until the

PLAY/STOP button

is pressed.

REPEAT All MESSAGES: While Playing

back a message, press the ERASE/REPEAT

button

twice; “REPEAT ALL” will appear in

the display and all messages in the selected

file folder will repeat over and over until the

PLAY/STOP button

is pressed.

To pause Recording or playback,

press the MODE/PAUSE button;

PAUSE will blink in the display.

Press the MODE/PAUSE button

again to resume recording or

playback.
