12822-2-0903
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
18
R-6126
Electrode and Wire Assembly
19
11712
Pilot Tubing (RH-50C-1)
19
11713
Pilot Tubing (RH-65C-1)
20
RH-457
Air Shutter Bracket
21
P-267
Manifold Assembly (RH-50C/CB-1)
21
P-268
Manifold Assembly (RH-65C-1)
22
P86-3.7mm Main Burner Orifice (RH-65C-1 Nat)
22
P86-3.1mm Main Burner Orifice (RH-50C-1 Nat)
22
P86-2.3mm Main Burner Orifice
(RH-65C-1 LPG)
22
P86-47
Main Burner Orifice
(RH-50C-1 LPG)
23
11746
Valve Bracket
24
R-6101
Gas Valve (Nat)
24
R-6102
Gas Valve (LPG)
25
11743
Control Rod
26
11700
Control Rod Bracket
27
R-6096
Knob & Adaptor Set
28
11722
Casing Side (RH-65C-1)
28
11721
Casing Side (RH-50C-1)
29
RH-653
Chamber Shield - Left
30
RH-656
Chamber Shield - Rear
31
R-926
Cable Assembly
32
R-2706
Eco Switch
Not Shown
742148
Pilot Orifice .011 (Nat)
Not Shown
742250
Pilot Orifice .008 (LPG)
Not Shown
R-2707
Junction Block Adaptor/ECO Switch
Not Shown
UH-441
Vent Safety Switch/ECO Hole
Cover Plate
1
11723
Diverter Assembly
2
RH-802
Down Draft Shield (RH-50C-1 NAT
& LPG)
2
RH-851
Down Draft Shield (RH-65C-1 NAT
& LPG)
3
11724
Draft Diverter Plate
4
11719
Casing Top (RH-50C-1)
4
11720
Casing Top (RH-65C-1)
5
11707
Louver (RH-50C-1, 3 Required)
(RH-65C-1, 4 Required)
6
11745
Casing Back
7
11741
Combustion Chamber Assembly
(RH-50C-1)
7
11742
Combustion Chamber Assembly
(RH-65C-1)
8
RH-654
Chamber Shield - Right (RH-50C-1)
8
RH-655
Chamber Shield - Right (RH-65C-1)
9
11721
Casing Side (RH-50C-1)
9
11722
Casing Side (RH-65C-1)
10
RH-618
Inner Front
11
RH-625
Bottom Reflector (RH-50C-1)
11
RH-660
Bottom Reflector (RH-65C-1)
12
RH-624
Rear Shield
13
11725
Casing Bottom Assembly
(RH-50C-1)
13
11726
Casing Bottom Assembly
(RH-65C-1)
14
RH-853
Burner
15
11755
Casing Front Assembly (USA)
15
15675
Casing Front Assembly (Canada)
16
R-776
Thermocouple
17
R-775L
Pilot Burner with Orifice (LPG)
17
R-775N
Pilot Burner with Orifice (Nat)
INDEX
PART
NO.
NUMBER
DESCRIPTION
INDEX
PART
NO.
NUMBER
DESCRIPTION
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
PARTS LIST RH-50C & RH-65C
