Battery Operation
The battery compartment is located on the bottom of the cabinet. Turn the unit
upside down and place the unit on a soft surface such as a bed, a towel, or on the
carpet, to avoid scratching the finish on the cabinet.
1.) Press down on the two “Arrow” marks on the battery compartment cover and
slide the cover in the direction of the arrows, as shown, to remove the cover.
2.) Insert 8 “C” (UM-2) batteries, not included, in the battery compartment. We
recommend that you use a well-known brand of alkaline batteries for longest
life and best performance. Be sure that the batteries are positioned according
to the polarity markings engraved in the battery compartment. If the batteries
are inserted incorrectly the unit will not work.
3.) Replace the battery compartment cover.
1
2
OP EN
OPE N
