ENGLISH

93

Switching the refrigerator on and off

• When connecting to the mains for the first time, the following symbols

appear on the screen.

• Normally, the appliance starts operating as soon as it is connected to

the mains, at the set temperature. The screen displays the following:
(the icon is lit up as the freezer is warm).

• Switching the appliance on and off is related to the freezer zone; this

means that, if the freezer is switched off, the whole refrigerator is
switched off. when the freezer is switched on, the whole appliance is
switched on. However, the refrigerator zone is independent; it can be
stopped in holiday mode, if required.

• Proceed as follows to switch on and off.

• To switch on, press key , the text line displays (" SET TEMP ") and should be flashing in

lower frame for the freezer zone. Use the + or – keys to display the temperature required, and
then press the key to select it. The refrigerator is switched on in the same way, except
the zone is in the upper part of the display.

• To switch the appliance off, press the key several times until the txt line displays "SET

TEMP" and the freezer temperature should be flashing. Use the – or + keys until the freezer
temperature disappears from the screen, then press key .

• After the refrigerator has been switched on, it has to be set.

• Open the setting menu by holding down (approx. 5 sec.) the key . Do the same for exiting

the menu.

• Once the menu is open, press the key to pass from one setting to another. The parameters

that can be changed are LANGUAGE, DATE, TIME, WARNING ACTIVE FOR POWER CUT.

20

20:30 VEN 11 MARS 05

5

°C

°C

-21

°C
