Page 6
- 6 -
Wire colors and connection points for connection wires
2
Never connect the power supply to the speaker wires (No.5 and No.6),
otherwise it will cause damage to the main unit.
Caution
ACC (Red)
Connect where the power comes on when the ignition is in the ACC position.
B+ (Yellow)
Connect where power is constantly available, regardless of the ignition key's position.
Ground (Black)
Connect where good body grounding is available.
Control power supply or automatic antenna power supply connection terminal (blue/white)
Connect to the power supply terminal for the power amplifier or other equipment, or to the vehicle’s automatic
antenna control terminal. (200mA max.)
Front speaker output wires
Connect to the front speakers.
White:
Left +
White/black:
Left -
Gray:
Right +
Gray/Black:
Right -
Rear speaker output wires
Connect to the rear speakers.
Green:
Left +
Green/black:
Left -
Purple: Right +
Purple/Black:
Right -
Cellular phone mute Wire (Pink)
Connect to the ground output terminal on a mobile phone.
7
6
5
4
3
2
1
English
E
spañol
Français
Italiano
Nederlands
Svenska
English
Main unit connections
Front line-out terminals
Connect to the RCA connector of an external amplifier.
Rear line-out terminals
Connect to the RCA connector of an external amplifier.
A
B
