Page 17 R-3451
Index Part
No. Number Description
Index Part
No. Number Description
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
Parts List for CIVF-25 Firebox
1 *CI-006 WINDOW RETAINING TAB
2 R-3948 WINDOW (BLACK PAINT)
2 R-3688 WINDOW (BLACK ENAMEL)
2 R-3696 WINDOW (SAND ENAMEL)
2 R-3704 WINDOW (GREEN ENAMEL)
2 R-3712 WINDOW (RED ENAMEL)
2 R-3720 WINDOW (NAVY ENAMEL)
3 R-3949 GRILL - LEFT (BLACK PAINT)
3 R-3726 GRILL - LEFT (BLACK ENAMEL)
3 R-3729 GRILL - LEFT (SAND ENAMEL)
3 R-3732 GRILL - LEFT (GREEN ENAMEL)
3 R-3735 GRILL - LEFT (RED ENAMEL)
3 R-3738 GRILL - LEFT (NAVY ENAMEL)
4 R-3950 GRILL - CENTER (BLACK PAINT)
4 R-3727 GRILL - CENTER (BLACK ENAMEL)
4 R-3730 GRILL - CENTER (SAND ENAMEL)
4 R-3733 GRILL - CENTER (GREEN ENAMEL)
4 R-3736 GRILL - CENTER (RED ENAMEL)
4 R-3739 GRILL - CENTER (NAVY ENAMEL)
5 R-3951 GRILL - RIGHT (BLACK PAINT)
5 R-3728 GRILL - RIGHT (BLACK ENAMEL)
5 R-3731 GRILL - RIGHT (SAND ENAMEL)
5 R-3734 GRILL - RIGHT (GREEN ENAMEL)
5 R-3737 GRILL - RIGHT (RED ENAMEL
5 R-3740 GRILL - RIGHT (NAVY ENAMEL)
6 R-3944 TOP (BLACK PAINT)
6 R-3683 TOP (BLACK ENAMEL)
6 R-3691 TOP (SAND ENAMEL)
6 R-3699 TOP (GREEN ENAMEL)
6 R-3707 TOP (RED ENAMEL)
6 R-3715 TOP (NAVY ENAMEL)
7 * CI-007 RETAINING TAB - 4 REQUIRED
8 R-3946 SIDE - RIGHT (BLACK PAINT)
8 R-3685 SIDE - RIGHT (BLACK ENAMEL)
8 R-3693 SIDE - RIGHT (SAND ENAMEL)
8 R-3701 SIDE - RIGHT (GREEN ENAMEL)
8 R-3709 SIDE - RIGHT (RED ENAMEL)
8 R-3717 SIDE - RIGHT (NAVY ENAMEL)
9 R-3947 FRONT (BLACK PAINT)
9 R-3687 FRONT (BLACK ENAMEL)
9 R-3695 FRONT (SAND ENAMEL)
9 R-3703 FRONT (GREEN ENAMEL)
9 R-3711 FRONT (RED ENAMEL)
9 R-3719 FRONT (NAVY ENAMEL)
10 * CI-009 LEG PAD “B” - 2 REQUIRED
11 * CI-008 LEG PAD “A” - 2 REQUIRED
12 * R-3747 LEVELING BOLT - 4 REQUIRED
13 R-3952 LEG - 4 REQUIRED (BLACK PAINT)
13 R-3742 LEG - 4 REQUIRED (BLACK ENAMEL)
13 R-3743 LEG - 4 REQUIRED (SAND ENAMEL)
13 R-3744 LEG - 4 REQUIRED (GREEN ENAMEL)
13 R-3745 LEG - 4 REQUIRED (RED ENAMEL)
13 R-3746 LEG - 4 REQUIRED (NAVY ENAMEL)
14 R-3945 SIDE - LEFT (BLACK PAINT)
14 R-3684 SIDE - LEFT (BLACK ENAMEL)
14 R-3692 SIDE - LEFT (SAND ENAMEL)
14 R-3700 SIDE - LEFT (GREEN ENAMEL)
14 R-3708 SIDE - LEFT (RED ENAMEL)
14 R-3716 SIDE - LEFT (NAVY ENAMEL)
* PART IS NOT SUPPLIED WITH CASTING, IT IS INCLUDED IN THE FIREBOX
HARDWARE PACKAGE
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
Index Part
No. Number Description
Index Part
No. Number Description
1 R-3436 REMOTE/OFF/ON SWITCH
2 CI-326 SWITCH BOX
3 CI-328 WIRE CHANNEL
4 CI-335 REAR COVER
5 CI-188 OUTLET BAFFLE
6 CI-287 INNER TOP
7 CI-391 REFLECTOR
8 CI-280 INNER BODY
9 CI-380 SCREEN FRAME ASSEMBLY
10 R-2708 PIEZO IGNITOR
11 CI-068 VALVE COVER ASSEMBLY
12 CI-253 MAGNET ASSEMBLY (2 REQUIRED)
13 * CI-008 LEG PAD-A (2 REQ’D)
14 * CI-009 LEG PAD-B (2 REQ’D)
15 CI-288 INNER BOTTOM FACE
16 CI-181 INNER BOTTOM ASSEMBLY
17 R-3625 GAS VALVE - LPG
17 R-3626 GAS VALVE - NAT
18 P-86-54L ORIFICE-LPG
18 P-86-40N ORIFICE-NAT
19 CI-176 MANIFOLD ASSEMBLY
Parts List for Stove Casting
20 CI-023 BURNER BRACKET - RIGHT
21 CI-258 AIR SHUTTER BODY - NAT
21 CI-259 AIR SHUTTER BODY - LPG
22 R-5278 BURNER
23 R-3623 PILOT ASSEMBLY-LPG
23 R-3624 PILOT ASSEMBLY-NAT
24 CI-180 PILOT TUBING
25 CI-166 BURNER BRACKET - LEFT
26 CI-347 LOG SUPPORT ASSEMBLY
27 CI-351 LOG SUPPORT BAFFLE
28 R-3642 FRONT LOG
29 R-3644 TOP LOG
30 R-3643 REAR LOG
NOT SHOWN CI-348 SWITCH BOX INSULATION
NOT SHOWN R-2789 ELECTRODE WIRE
NOT SHOWN * R-3747 LEVELING BOLT (4 REQUIRED)
NOT SHOWN * CI-007 RETAINING TAB (4 REQUIRED)
NOT SHOWN R-3765-A WIRE ASSEMBLY
NOT SHOWN M-166 MANIFOLD ORIFICE GASKET
* PART IS INCLUDED IN THE HARDWARE PACKAGE AND IS USED IN THE
ASSEMBLY OF THE STOVE CASTING
