1 1/ INSTALLING YOUR APPLIANCE EN
4
• • CHOICE OF LOCATION
The distance between the edge of your appliance
and the side and rear walls (or partitions) must be
at least four centimetres (zone A).
Y
Yo ou urr a ap pp plliia an nc ce e m ma ay y b be e b bu uiilltt iin n w wiitth ho ou utt a an ny y
rre es sttrriic cttiio on n.. C Ch he ec ck k,, h ho ow we ev ve err,, tth ha att tth he e a aiirr iin ntta ak ke es s
a an nd d o ou uttlle etts s a arre e ffrre ee e o off o ob bs sttrru uc cttiio on n..
The building-in method opposite is
recommended for use above an oven or built-in
appliance.
The ventilation space is essential in all
configurations.
BUILDING-IN
Follow the diagram above.
Glue the foam seal underneath the appliance,
following the perimeter of the hole in the worktop,
upon which the appliance will rest. This will
ensure a good seal against the worktop.
• •
Tip
If your hob is located above an oven, the hob’s thermal safety devices can impede the
simultaneous use of the hob and the oven’s pyrolysis program.
The hob is equipped with a safety system to prevent overheating.
This safety device can be activated, for example, when the hob is installed above an oven that is
not sufficiently well insulated. In such circumstances we recommend that you improve the hob’s
ventilation by creating an opening in the side of the cabinet, (8 x 5 cm), and/or also installing an
oven insulation kit available from our after-sales department (Ref. 75X1652).
You can also install your hob above a dishwasher. In that case, your worktop must be at least
900mm high in order to ensure the proper ventilation of your hob and you could also fit the
dishwasher insulation kit that is available from the after-sales Service (Ref. 77X7781).
A Ab bo ov ve e a a c ca ab biin ne ett
w wiitth h a a d do oo orr o orr d drra aw we err
M MIIN NII 4 4 m mm m
4 40 0m mm m
V VE EN NT TIIL LA AT TIIO ON N S SP PA AC CE E
A Ab bo ov ve e a an n o ov ve en n
