EdgeStar IB1000SS - Manual (Page 20)

17
Specifications
Description of product Full Size Ice Maker Full Size Ice Maker Full Size Ice Maker
Model IB650SS IB1000SS IB1500SS
Voltage/Frequency AC 115V~60Hz AC 115V~60Hz AC 115V~60Hz
Ice-Making / Ice-Harvest
rated current 6.7A / 11.2A 7.3A / 11.7A 7.5A / 11.8A
Color Stainless Steel;
Black Door
Stainless Steel;
Black Door Stainless Steel;
Black Door
Type of Ice Bullet Cube Bullet
Ice Storage capacity 24 lbs maximum 35 lbs maximum 35 lbs maximum
Ice-making capability 65 lbs / day ** 83 lbs / day ** 110 lbs / day **
Refrigerant R134a, 6.88 oz. R134a, 8.96 oz. R134a, 9.92 oz.
High / Low side pressure 320psig / 120psig 320psig / 120psig 320psig / 120psig
Dimensions
(Width x Depth x Height) 16.5” x 21.3” x 33.1” 22.0” x 21.3” x 33.5” 22.0” x 21.3” x 33.5”
Weight 91 lbs 106 lbs 102 lbs
Note: Technical data and performance information provided for reference
only.
Specifications are subject to change. Check the rating label on the ice
maker for the most accurate information.
* The actual quantity of ice produced per day will vary with room and
water conditions.
Notes on ice storage
The ice maker will automatically shut off when the ice bin is full. The ice
bin compartment is insulated, but not refrigerated and the ice in the bin
will slowly melt and go out the drain. Once enough of the ice has melted,
the ice maker will automatically start making more ice.
