AND-TFT-35VX-UHB-TS
TFT LCD + Touch Panel
Pin Description - Input/Output Terminals Pin Description - Input/Output Terminals Pin Description - Input/Output Terminals Pin Description - Input/Output Terminals
Pin No. Symbol I/O Description
1 DIO1 I/O Horizontal Start Pulse SIgnal Input or Output 1 Horizontal Start Pulse SIgnal Input or Output 1
2 VSS2 I Ground
3 VDD1 I Power Supply Power Supply
4 CLK I Horizontal Shift Clock
5 R/L I Left/Right Selection Left/Right Selection
6 R0 I Red Data (LSB) Red Data (LSB)
7 R1 I Red Data
8 R2 I Red Data
9 R3 I Red Data
10 R4 I Red Data
11 R5 I Red Data (MSB) Red Data (MSB)
12 VSS2 I Ground
13 G0 I Green Data (LSB) Green Data (LSB)
14 G1 I Green Data
15 G2 I Green Data
16 G3 I Green Data
17 G4 I Green Data
18 G5 I Green Data (MSB) Green Data (MSB)
19 B0 I Blue Data (LSB) Blue Data (LSB)
20 B1 I Blue Data
21 B2 I Blue Data
22 B3 I Blue Data
23 B4 I Blue Data
24 B5 I Blue Data (MSB) Blue Data (MSB)
25 LD I Load Output SIgnal Load Output SIgnal
26 REV I Data Invert Control
27 POL I Polarity Selection Polarity Selection
28 DIO2 I/O Horizontal Pulse Signal Input or Output Horizontal Pulse Signal Input or Output
29 VSS2 I Ground
30 V3 I Gamma Voltage 3 Gamma Voltage 3
31 V5 I Gamma Voltage 5 Gamma Voltage 5
32 V7 I Gamma Voltage 7 Gamma Voltage 7
33 V8 I Gamma Voltage 8 Gamma Voltage 8
34 V10 I Gamma Voltage 10 Gamma Voltage 10
35 V12 I Gamma Voltage 12 Gamma Voltage 12
36 VSS2 I Ground
37 VDD2 I Voltage for Analog Circuit Voltage for Analog Circuit
38 VCOM I Common Voltage Common Voltage
39 OE I Output Enable Output Enable
40 U/D I Up/Down Selection Up/Down Selection
41 CKV I Vertifcal Shift Clock
42 STVU I/O Vertical Shift Pulse Signal Input or Output Vertical Shift Pulse Signal Input or Output
43 STVD I/O Vertical Shift Pulse Signal Input or Output Vertical Shift Pulse Signal Input or Output
44 VGG I Gave on Voltage Gave on Voltage
45 VSS1 I Ground
46 VCC I Voltage for Logic Circuit Voltage for Logic Circuit
47 VEE I Gate Off Voltage Gate Off Voltage
48 VLED – Supply Voltage for LED Backlight Supply Voltage for LED Backlight
49 GLED2 – Ground for LED Backlight
50 GLED1 – Ground for LED Backlight
