AND-TFT-43LP-KIT
TFT LCD Color Module
Item
Symbol
I/O
Specifi cations
Unit
Remark
Min.
Typ.
Max.
Input Voltage
Vin
I
+10
+12
+14
V
Total Current
Iin
I
–
–
–
mA
Power Consumption
=
I
–
–
–
W
@ +12V
Output Voltage
VDD
O
+3.2
+3.3
+3.4
V
I=10mA
Video Input Signal
Video in
I
–
1.0
–
Vp-p
@ 75 Ω
Analog RGB Input Signal
Analog RGB in
RGB
–
0.7
–
Vp-p
@ 75 Ω
Electrical Characteristics - Recommended Operating Conditions (Ta = 25ºC)
Optical Specifi cations
(Ta = 25 ºC)
Item
Symbol
Remarks
Min.
Specifi cations
Typ.
Max.
Units
Viewing Angle
Horizontal
Left
CR ≥ 10
65
75
–
deg
Right
65
75
–
Vertical
Top
50
60
–
Bottom
60
70
–
Contrast Ratio
Luminance when LCD is white
Luminance when LCD i black
CR
θ
= 0º
480
600
–
–
Response Time
Rise
Tr
θ
= 0º
—
3
6
ms
Fall
Tf
θ
= 0º
—
7
14
ms
Brightness
LUM
450
500
–
cd/m
2
Uniformity (%)
U
70
75
–
%
White
Chhromaticity
x
θ
= 0º
0.26
0.31
0.36
–
y
θ
= 0º
0.28
0.33
0.38
–
LED Life Time
+25º
20,000
—
—
Hr
Block Diagram
