6
Movable shelves
The walls of the refrigerator have runners so that the
shelves can be positioned as desired .
For better use of space, the front half-shelves can lie
over the rear ones.
D338
Bottle rack
Place bottles in the rack with the bottleneck to the
front.
Important: Only store unopened bottles horizontally.
The bottle rack can be tilted for storing opened
bottles.
To do this pull the bottle rack forward until it can be
tilted upwards, then slide the front support into the
next level up.
Positioning the door shelves
To permit storage of food packages of various sizes,
the door shelves can be adjusted in height. To do
this proceed as shown in the diagram.
The top shelf can be removed for easier cleaning.
15
Instructions for totally built-in appliances
Recess dimensions
Height (1) 1225 mm
Depth (2) 550 mm
Width (3) 560 mm
The appliance’s door has been locked in position
for transport by means of pins on both sides.
According to the door opening direction, remove
relevant pins at the top and at the bottom.
To ensure adequate ventilation, allow the clearances
shown in figure.
Furthermore, it is necessary that the cabinet has a
ventilation recess with the following dimensions:
depth 50
mm
width 540 mm
50 mm
min.
200 cm
2
200 cm 2
min.
D567
Push appliance into housing until stop strip (A)
touches the kitchen unit.
Open the door and push the appliance against the
side of the kitchen unit opposite to that of appliance
hinges.
Fasten the appliance with 4 screws provided in the
kit included with the appliance.
Snap ventilation grille (C) and hinge cover (D) into
position
A
D022
D727
C
D
PR01
540
50
3
2 1
