COOLING GROUP
-19-
Item
Part No.
Description
Qty.
1 1-303287 Tie, Cable 5 1/2 (Small) ......................... 3
2 1-513645 Bushing.................................................. 1
3 1-513658 Bumper .................................................. 2
4 1-633989 Clamp .................................................... 4
5 1-643161 Cap, Radiator......................................... 1
6 1-643163 Tank, Overflow....................................... 1
7 1-643164 Cap, Overflow Tank ............................... 1
8 1-643189 Keeper, Rubber Latch ............................ 2
9 1-643259 Fitting, Elbow ......................................... 1
10 109-8431 Hook, Latch............................................ 1
11 923786 Rivet ...................................................... 4
12 103-1479-03 Wld, Rear Bumper ................................. 1
13 103-6643 Spring .................................................... 1
14 103-7532 Hose, Radiator ....................................... 1
15 103-7558-03 Rib, Top ................................................. 1
16 103-7579-03 Rib, Bottom ............................................ 1
17 109-8546-03 Wld, Rear Radiator Mount...................... 1
18 109-2804 Asm, Front Radiator Mount W/Decal...... 1
19 321-6 Screw, HH 1/4-20 x 1 ............................. 4
20 103-9207 Rod, Prop............................................... 1
21 109-8539 Asm, Latch Plate W/Decals ................... 1
22 103-9214-03 Bracket .................................................. 1
23 103-9218 Pin, Cover Pivot ..................................... 2
24 109-0089-03 Bracket, Hydraulic Tank ......................... 1
25 107069 Nut, Retainer Panel................................ 4
26 109-9195 Fan, 14” Electric..................................... 1
27 32128-20 Nut, Whizlock 5/16-18............................ 15
28 109-8541 Kit, Fan 16” ............................................ 1
Item
Part No.
Description
Qty.
29 109-2669 Hose ...................................................... 1
30 109-2950 Mount, Fan ............................................ 4
31 109-3142 Hose, Radiator....................................... 1
32 109-3143 Hose, Overflow ...................................... 1
33 109-3179-03 Wld, Hinge Plate.................................... 2
34 32120-18 E-Ring ................................................... 2
35 321-2 Screw, HH 1/4-20 x 1/2.......................... 2
36 109-8732-03 Shroud, Fan........................................... 1
37 322-10 Screw, HH 5/16-18 x 2........................... 1
38 322-3 Screw, HH 5/16-18 x 3/4........................ 12
39 322-4 Screw, HH 5/16-18 x 7/8........................ 15
40 322-5 Screw, HH 5/16-18 x 1........................... 1
41 3234-47 Screw, HH FLG 5/16-18 x 3/4 ................ 4
42 112-6950 Bolt, Carriage 5/16-18 x 1 3/8, short neck.. 2
43 3253-3 Washer, Lock 1/4 .................................. 4
44 3253-4 Washer, Lock 5/16................................. 12
45 3256-22 Washer, 1/4 SAE ................................... 6
46 3256-23 Washer, 5/16 SAE ................................. 31
47 3296-29 Nut, Nyloc 5/16-18 ................................. 1
48 32128-25 Nut, Hex 5/16-18 Side Lock ................... 1
49 3256-3 Washer, 5/16 Std................................... 1
50 107-0075 Spacer ................................................... 1
51 109-8430 Spring .................................................... 1
52 109-8432 Pin, Latch .............................................. 1
53 1-303334 Washer, Spring Disc 5/16 ...................... 1
54 99-8551 Plug, Pipe .............................................. 1
55X 109-8733 Asm, Radiator........................................ 1
Exmark black touch up spray paint – gloss black.
X Radiator assembly does not include items, #1 or #32.
