Eureka 2940-2969 Series User Manual
Page 12

12
ENGLISH
PERIODIC MAINTENANCE
How To Replace Brushroll Belt
Step 1: Lower handle to floor to change belt (FIG. 21).
Step 2: Remove the two screws from the top of the hood (FIG. 22).
Step 3: Lift hood to remove (FIG. 23).
ESPAÑOL
MANTENIMIENTO PERIÓDICO
Cómo cambiar la correa del cepillo circular
Paso 1: Baje el mango hasta el suelo para cambiar la correa
(FIG. 21).
Paso 2: Quite los dos tornillos de la tapa de la base (FIG. 22).
Paso 3: Levante la tapa para quitarla (FIG. 23).
FIG. 21
FIG. 22
FIG. 23
(CONTINUACIÓN)
(CONTINUED)
Edge Kleen™ model shown
(some models only)
Se muestra el modelo Edge Kleen™
(sólo algunos modelos)
Edge Kleen™ model shown
(some models only)
Se muestra el modelo Edge Kleen™
sólo algunos modelos)
