INTRODUCTION
Installation and Operations Manual 1
Disclaimer
While every precaution has been taken in the preparation of this manual, the
manufacturer assumes no responsibility for errors or omissions. Neither
does the manufacturer assume any liability for damages resulting from the
use of the information contained herein. The manufacturer reserves the
right to change the specifications, functions, or circuitry of the product
without notice.
The manufacturer cannot accept liability for damages due to misuse of the
product or other circumstances outside the manufacturer’s control. The
manufacturer will not be responsible for any loss, damage, or injury arising
directly or indirectly from the use of this product.
System introduction
Thank you for choosing the Rose Electronics

CrystalLink
 USB 2.0 Fiber
extender. The CrystalLink USB 2.0 Fiber extender is the result of Rose
Electronics commitment to providing state-of-the-art solutions for today’s
demanding workplace. The CrystalLink USB 2.0 Fiber has proven to be a
valuable investment for any business, big or small, that has a need to
access and extend their USB 1.1 or 2.0 peripherals from a remote location.
This location can be up to 1640 feet (500m-Mulitmode model) or 6 miles (10
km-Singlemode model).
The receiver unit’s USB port connects to your USB peripheral. The number
of peripherals can be increased by using a standard USB hub.
The USB peripherals can be USB 1.1 devices (low-speed or full-speed) or
USB 2.0 high-speed devices operating up to 480 Mb/s. The receiver unit
can supply up to 500 ma for driving high-power USB devices.
Plug-and-play installation makes installing the transmitter and receiver
simple and easy. Connect the transmitter to the computers USB port,
connect the USB port on the receiver to your USB device, connect the
transmitter to the receiver with Singlemode or Multimode fiber cable
(depending on your model), connect the provided power adapter to the
transmitter and receiver and power on the system.
The USB devices will function normally as if they are directly connected to
your computer’s USB port even though they are up to 6 miles away.
NOTE: The provided 5V, 3.0A power adapter connects to the receiver.
An optional 5V, 0.5A power adapter connects to the transmitter unit
if the host PCs USB port does not supply the needed power.
