INSTALLATION
Installation:
) Locate & mark the 2x4’s,
outline the hole using the
1
s u p p l i e d s p e a k e r
template–stay clear from the 2x4s.
) Using a drywall saw, cut out
the opening.
2
) Attach speaker wire, and insert
the Image-846 speaker into the
3
wall opening.
) Align the speaker in position,
and tighten the screws evenly to
4
secure the unit.
) Align the grille in position.
Gently push the cover into
5
place.
Final
