13
2.6.2 Mounting: Hinged to tilt up for access to hydraulic pumps, battery and other
components. Held in tilted position with scissor-type links. Adjustable fore and aft seat
track.
2.6.3 Armrests:
Molded adjustable flip-up
armrests.
2.6.4 Seat Safety Switch: Incorporated into the Safety Interlock System. Time delay seat
switch eliminates rough ground cut-outs.
2.7 HYDROSTATIC GROUND DRIVE SYSTEM
2.7.1
Hydrostatic Pumps: Two Hydro Gear PW variable displacement piston pumps.
2.7.2
Wheel Motors: Two Parker/Ross with 1 1/4” tapered shafts.
2.7.3
Hydraulic Oil Type: Use Mobile 1 15W-50 Synthetic motor oil.
2.7.4
Hydraulic Oil Capacity: 5.5 qt. (5.2 L.)
2.7.5
Hydraulic Filter: Replaceable cartridge type.
P/N 103-2146: 25 microns, No bypass
2.7.6
Speeds: 0-12.0 mph (19.3 km/hr) forward
0-8.0 mph (12.9 km/hr) reverse
2.7.7
Drive wheel release valves allow machine to be moved when engine is not running.
2.8 TIRES
Drive Front
Caster
Pneumatic
(Air-Filled)
Semi-Pneumatic
Quantity 2
2
Tread
“Multi-Trac C/S”
Smooth
Size
26 x 12.00-12
13 x 6.50-6
Ply Rating
4
Pressure
10 psi (69 kPa)
2.9 CUTTING DECK
2.9.1
Cutting Width:
60 in. (152.4 cm)
66 in. (167.6 cm)
72 in. (182.9 cm)
2.9.2
Discharge: Side
2.9.3
Blade Size: (3 ea.) 60” Deck: 20.75 in. (52.7 cm)
66” Deck: 22.75 in. (57.8 cm)
72” Deck: 24.75 in. (62.9 cm)
2.9.4
Blade Spindles: Solid steel spindles with 1.18 in (3.00 cm) I.D. bearings.
2.9.5
Deck Drive: Electric clutch mounted on horizontal engine shaft. “B” Section belt
(with self-tensioning idler) from electric clutch to transfer shaft mounted on deck.
Blades are driven by one “B” Section belt (w/self-tensioning idler) from transfer
shaft on deck to blade spindles.
2.9.6
Deck: Full floating deck is attached to out-front support frame. Six anti-scalp
rollers provide maximum turf protection. Deck design allows for bagging, mulching
or side discharge.
Deck
Depth: 60” Deck: 6.0” (15.2 cm)
66” Deck: 6.0” (15.2 cm)
72” Deck: 6.0” (15.2 cm)
2.9.7
Cutting Height Adjustment: an extra-long cushioned lever is used to adjust the
cutting height from 1” (2.5 cm) to 5” (10.2 cm.) in 1/4”(.64 cm) increments. The
cutting height adjustment handle has a transport position and all adjustments
can be made while the operator remains seated. Units also have a foot
operated deck lift assist lever to aid in raising the deck.
2.9.8
Mulching Kit: Optional.
