3024C Actuator
Instruction Manual
Form 5760
March 2007
14
Figure 7. Actuator Dimensions with Handwheel
1Q57490
REVERSEĆACTING DIRECTĆACTING
H
S
H
S
J
S
J
S
M
M
Parts Ordering
Each actuator has a serial number stamped on the
nameplate (figure 2 and key 34 on figures 8 and 9).
Refer to the serial number when ordering
replacement parts or when corresponding with your
Emerson Process Management sales office for
technical assistance. Also specify the complete 7 or
11 character part number from the following parts list
when ordering replacement parts.
WARNING
Use only genuine Fisher r replacement
parts. Components that are not
supplied by Emerson Process
Management should not, under any
circumstances, be used in any Fisher
valve, because they will void your
warranty, might adversely affect the
performance of the valve, and could
give rise to personal injury and
property damage.
Note
Neither Emerson, Emerson Process
Management, nor any of their affiliated
entities assumes responsibility for the
selection, use and maintenance of any
product. Responsibility for the
selection, use, and maintenance of any
product remains with the purchaser
and end-user.
