Elkay EDFP217C User Manual
Page 8
97705C (Rev. J - 8/07)
EDFP217C*B EDFP217RAC EDFPVR217C EDFPVR217RAC
PAGE 8
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
ELKAY MANUFACTURING COMPANY • 2222 CAMDEN COURT • OAK BROOK, IL 60523 • 630.574.8484
PART NO.
ITEM NO.
PARTS LIST
DRAIN
RETAINING NUT
PUSH BUTTON
PUSH BUTTON SLEEVE
REGULATOR HOLDER
ORIFICE ASSY
HOUSING ASSY
PEDESTAL
BUBBLER LOCKNUT
REGULATOR
CAP SCREW
SCREW - #10-24 X .50 PHTC
STRAINER
FOUNTAIN ARM - SHORT
FOUNTAIN ARM - LONG
FOUNTAIN ARM - LONG (GLASSFILLER)
BOTTOM COVER PLATE - SHORT
BOTTOM COVER PLATE - LONG
BACK PANEL RH ADA
BACK PANEL LH ADA
HEX NUT
REGULATOR MOUNTING BRACKET
GASKET - (VR MODEL ONLY)
BUBBLER - NIPPLE - (VR MODEL ONLY)
BUBBLER - (VR MODEL ONLY)
POLY TUBING (CUT TO LENGTH)
BRACE-CHANNEL
TEE - 1/4
BRACKET - HANGER PANEL
LK464
15005C
45662C
45663C
50986C
A54874
56011C
55997C
75580C
61313C
75672C
112627543890
55996C
28782C
28783C
27959C
55000661
55000665
28250C
28252C
40045C
27057C
100322740560
15009C
45392C
56092C
28234C
70682C
27090C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
NS
NS
DESCRIPTION
FIG. 10
14
SEE FIG. 7 OR 8
16
SEE
FIG. 11
12, 15
1
13
22
FIG. 11
3
4
17
2
10
5
11
18
