7. Drill holes from the markers, then insert the Plastic Screw Anchors (#1) into the holes as shown in FIG.4 & 4A. .

Note: Do not drill holes on a cement wall or a wall made with metal studs.

8. Insert two Screws (#2) into the Screw Anchors (#1) and place the Scoreboard (#3) onto the Screws as shown in

FIG.4 & 4A. .
Note: The Screws must partially stick out in order to hang the Scorer.

9. Insert 4 AA batteries (not included) into the backside of the Scoreboard. Batteries must be installed according to

the correct polarization required as shown in Fig.4B.

FIG. 4

FIG.4A

FIG.4B
