19
4-INSTALLATION AND ASSEMBLY
HEIGHT AND LEVEL ADJUSTMENT
The Forma Wood closed fireplace is equipped with adjustment feet which enable to adjust the level of the closed fireplace hearth by
approximately 2/3 cm.
If one wishes to raise the closed fireplace by over 2/3 cm one must create a brickwork pedestal on which to place the product.
In any case do not remove the feet that are essential for levelling.
Removing the feet is considered a structural modification of the product and therefore it makes the warranty void.
Levelling the closed fireplace is an essential operation for the hearth door to slide properly.
In the event of a floor made of flammable material, the lower part of the closed fireplace (C) must be at least 5 cm
away from the floor. Fig.4
CHECK THE DOOR SLIDING SEVERAL TIMES BEFORE CLOSING THE FIREPLACE WITH THE CLADDING.
If the closed fireplace is not positioned level, there is a risk that the door does not close properly and that the internal
counterweights knock against the structure causing noise every time one lifts and lowers the door.
It is recommended to use the wheels (supplied) when one must move the closed fireplace; the feet are then sufficient for levelling.
FIGURE 4 - SAFETY MEASURES
